4-3. WORKING WITH THE OPS200

Reseting default values
It is strongly recommended resetting all of the default values of your
OPS200 unit before setting up your shows and events. To do so,
press the [EXIT/MENU]
rotating the corresponding knob. Then press the
enter the Control sub-menu. Select Default Values by rotating the
scroll knob, and press the
restart your OPS200 with its factory settings. This operation should
take approximatly 30 seconds.

OPS200 color codes

Analog Way engineers have developped a handy, user friendly way
of identifying machine status on the front panel, via the use of color
codes on the buttons of the machine. All new Analog Way machines
use the same codes, for quick recognition of the status of any device
of the range, at any given time.
For the OPS200, button color codes are as follow:
- Sources on the Main output are indicated in red when active.
- Sources on the Preview output are indicated in green when active.
- Buttons in the layer section turn red or green, depending on
whether the selected layer is active in respectively the Main or
Preview window.
- Menu buttons are indicated in green.
- Selecting a button with an available source or function will cause
that button to blink green on the preview, or red once it is on the
Main output.
- [TAKE] button reacts as follows:
If take function is available, the button will appear in green.
When the take function is active, it will light up red.
#1 = Source, Layer or Window is on Main
Solid red:
#2 = Freeze enable
#1 = Source or Layer is on Preview
#2 = Function available for modification
Solid green:
#3 = Current output on Matrix Mode
button and select Control in the menu by
[ENTER] button to enter your choice to
[ENTER] button to
Blinking red: Active Layer or Source for modification on Main
Blinking green:
Active Layer or Source for modification on Preview
