2-2. UNPACKING AND INSPECTION

1 x OPS200 seamless scaler/switcher
1 x Power supply cord
2 x DVI male to HD15 female and DVI female cable
1 x HD15 to 5 BNC cable
1 x Ethernet cross cable (for device update)
1 x Set of 3 audio 10-pin screw terminals
1 x RCS (Remote Control Software) CD-ROM (PC only) *
1 x User manual (PDF version) *
1 x Quick Start guide (PDF version) *
* Download on our website:

2-3. RACKMOUNT INFORMATION

Tabletop mounting: The
rubber feet.
Rack mounting: The
install the device in a 19" rack.
Place the device in your rack. Attach the device to the rack by using 4 screws through the front panel holes
(screws not included).
Rear fixing is also recommended, in particular for permanent installations. The
holes designed for compatibility with most rackmount braces.
Connect all of the cables of the device and attach them to the rack with the help of tie wraps.
IMPORTANT:
- The openings in the side and rear panels of the device are for cooling. Do not cover these openings to
avoid cutting air circulation.
- Be sure that no weight in excess of 2 kg (4.4 Lbs.) is added onto the OPS200.
- The maximum ambient operating temperature should not exceed 40°C (104°F)
- The rack and all mounted equipment in it must be reliably grounded according to national and/or local
electrical standards.
Dismantling front handles of the device could invalidate warranty on after sales services of your
!
OPS200. It is strongly advised to avoid using front handles as rests for your OPS200, they are
designed for manipulation purposes only.
If required, front handles of the device can be dismantled, but with caution.The original screws removed
must not be reintroduced to their location without handles in place. Substancial damages can occur,
including risk of electric shock from the main voltage. Only M4x12mm screws can be used. They are
supplied with the unit.
10
www.analogway.com/
OPS200 can be used directly on a table, the unit is equipped with 4 handy anti-slip
OPS200 is compatible with a 19" enclosure. Please follow the instructions below to
OPS200
is equipped with drill
