4-2. THE OPS200 MENU

Menu navigation

To access the OPS200
the menu which will appear on the VFD screen (2), turn the scroll knob (3) left or right to the desired menu
item. When you have reached the desired menu item, press the
access that menu function. Pressing the
that selection in the
exit sub-menus and return to the main menu.
* IMPORTANT *: simply selecting a menu item will not set it to that value. Be sure to press the ENTER button
when parametering the menu items.

Home menu

Pressing the MENU button in the menu section of the OPS200, will display and give you access to the
following items on the menu VFD screen:
- INPUT: select to configure the 11 individual input types and resolutions.
- MAIN OUT: select to set the output types and resolutions of the Main output.
- PREVIEW OUT: in Mixer mode, select to set the output types and resolutions of the Preview output.
- PRESET: select to store and use presets.
- IMAGE: select to change source image settings of an input.
- KEYING/TITLING:
- LAYER: select to adjust layer size, position, border, transparency or transitions.
- LOGOS/FRAMES:
- AUDIO: select to access all audio input and output parameters.
- CONTROL:
select to access device software information, LAN settings, reset factory settings, a m o n g s t
other user oriented functions.
26
menu, press the [EXIT/MENU]
[ENTER]
OPS200 memory. When all settings have been made, press the
select to access keying and titling controls and parameters.
select to store (record), use and manage logos and frames into the OPS200.
button in the control section (4). To highlight items in
[ENTER]
button when a selection has been made sets the value to
button in the control section (4) to
[EXIT/MENU] button to
