6. CARE AND MAINTENANCE

Clean the exterior with a soft, lint-free, anti-static
cloth. Do not use force while wiping the surface.
To remove difficult stains use a few drops of
detergent on a moist cloth, sweep carefully and
wipe dry afterwards.
If some scratching might occur, please first consult
your Sphinx dealer. He can give you advice about
possible solutions.
7. TECHNICAL SPECIFICATIONS
Bandwidth
Phase response error
Gain
Minimum Power Output (1 - 20,000 Hz)
Output voltage / current, max.
THD+N (IHF-A)
IMD
S/N ratio (IHF-A)
Common Mode Rejection Ratio
Slew rate
Damping factor
Input
level, nominal
impedance
Supply capacitance
Power consumption
Dimensions (h x w x d)
Weight
This unit conforms to the EMC interference regulations from the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and thus with international safety regulation IEC 65.
Technical specifications can be changed by SPHINX without prior notice if technical developments make this
necessary.
©1999 Audioscript BV
SPHINX
Do not use polishing or cleaning agents: they
may damage the sensitive acrylic finish.
Do not use aerosol cleaning agents.
Most contain solvents which might actively react
and damage the acrylic finish.
0 - 100,000 Hz (+0/-1 dB, with input filter)
<1° (0 - 20,000 Hz)
30 dB max.
>2x 160 W into 8 ohm (22.0 dBW), THD<0.01%
>2x 280 W into 4 ohm (24.5 dBW), THD<0.01%
>2x 420 W into 2 ohm (26.2 dBW), THD<0.01%
36 V / 43 A
<0.01% (1 W into 8 ohm, 1 - 20,000 Hz)
<0.01% (100 W into 8 ohm)
>120 dB (1 W into 8 ohm)
>80 dB (@ 100 Hz)
>50 V/µs
>2000 (1 - 20,000 Hz)
cinch: unbalanced / XLR: balanced
1.25V ( 1.9 dBV) / 1.25 V ( 1.9 dBV)
20 kohm / 600 ohm
132,000 µF total
1500 W max. (70 W standby)
143 x 482 x 452 mm
24 kg
Project Eighteen
