System Board

NOTE: All system board spare part kits include replacement thermal material.
Description
System board for use in models without Windows 8
System board for use in models with NetClone
System board for use in models with Windows 8 with no Digital Product Key (DPK)
System board for use in models with Windows 8 Standard
System board for use in models with Windows 8 Professional
The system board is secured to the computer with six screws.
1. Prepare the computer for disassembly
2. Remove the access panel
3. When replacing the system board, make sure the following components are removed from the
defective system board and installed on the replacement system board:
●
Memory modules
●
Expansion cards
●
Heat sink
●
Processor
4. Remove the fan from the chassis
5. Rotate the drive cage to its upright position.
6. Rotate the power supply to its full upright position.
7. Disconnect all data and power cables from the system board.
8. Disconnect the balance of the cables from the system board.
9. Remove the six screws that secure the system board to the chassis.
138 Chapter 8 Removal and Replacement Procedures – Small Form Factor (SFF) Chassis
(Access Panel on page
(seeMemory on page
(Expansion Card on page
(Fan Sink on page 131)
(Processor on page 133)
(Fan Assembly on page
(Preparation for Disassembly on page
102).
105)
110)
129).
Spare part number
663099-001
711493-001
702644-001
702644-501
702644-601
101).
