Access Panel
Description
Access panel
1.
Prepare the computer for disassembly
2.
If the computer is on a stand, remove the computer from the stand.
3.
Remove the Torx screw that secures the access panel to the computer.
Figure 8-1
102 Chapter 8 Removal and Replacement Procedures – Small Form Factor (SFF) Chassis
Removing the access panel screw
(Preparation for Disassembly on page
Spare part number
656832-001
101).
