5.0 COMBUSTION MONITORING SYSTEM
This fire is fitted with a combustion monitoring safety device (ODS). If the appliance shuts down during use
for no apparent reason then several reasons may be suspected. If a door or window has been opened cre-
ating a draught, then pilot disturbance could be the problem and removal of the draught should resolve
this. The appliance can then be re-lit in accordance with the previous section.
If pilot disturbance is not the cause, then the ODS safety system may be in operation. Switch the appli-
ance OFF, call in your installer to check the appliance and ventilation. Remedial work must be carried out
as required. DO NOT allow the appliance to be used until the appliance and installation is passed as safe.
If the pilot continues to be extinguished, you must call your installer to check the operation of the com-
plete appliance.
CLEANING
6.0
Before carrying out any of the following operations, ensure that the appliance is OFF and completely cold.
INNER GLASS PANEL -
er. Test on a small area first.
GLASS FACIA PANEL - This should only be cleaned using a suitable glass cleaner. Test on a small area first.
PAINTED AREAS - These can be cleaned using a dry cloth.
STAINLESS STEEL AREAS - These can either be cleaned using a proprietary stainless steel metal cleaner or
baby oil. Test on a small hidden part of the stainless steel before cleaning. Always clean in the direction of
the grain.
SERVICING
7.0
The appliance should be checked on an annual basis to ensure it is working safely. The frequency of serv-
ice will depend on usage, but MUST be carried out at least once annually. Servicing must be carried out
by a competent
The Installation instructions carry full servicing details for the use of the installer.
8.0

LIST OF SPARE PARTS

PART NO.
F960003
FT003155/1
F780081
Please enquire
As our policy is one of continuous improvement and development , we hope therefore you will understand we must retain the right to amend details and/or spec-
ifications without prior notice.
[1] GB - Gas Safe TM registered operatives (Northern Ireland only- CORGI registered operatives) are the only class of person considered as competent by the HSE under
the Gas Safety (Installation and Use) Regulations 1998.
This can be cleaned with a suitable glass cleaner, or propriety ceramic hob clean-
[1] person.
ITEM
Inner glass door assembly
Gas valve
Catalyst
Burner tray
PART NO.
F730023
F730048
F940136
3
ITEM
Pilot unit (NG models)
Pilot unit (LPG models)
Seal kit for Catalyst
F860623
©
