installation and user instructions
All instructions must be handed to user for safekeeping
Revision A - 06/09
Country(s) of destination - GB/IE
eko 2010
eko 2020
fuel effect gas fire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eko 2010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ekofires eko 2010

  • Page 1 All instructions must be handed to user for safekeeping Revision A - 06/09 Country(s) of destination - GB/IE eko 2010 eko 2020 fuel effect gas fire...
  • Page 2: Installation Instructions

    INSTALLATION INSTRUCTIONS Eko 2020 Eko 2010 Preliminary Notes Before Installation This appliance is an Inset Live Fuel Effect appliance which provides radiant warmth utilising the latest type burner technology. The fire is designed to fit various types of fireplaces and natural draught flues as listed in the Installation Requirements.
  • Page 3: Table Of Contents

    Section Page No. Contents Section Contents Page No. Important Notes 10.0 Gas Supply Appliance Data 11.0 Fitting the Firebox Installation Requirements 11.1 Cable Fixing Site Requirements 11.2 Gas Connection Ventilation 12.0 Fuel Bed Layout (coal versions) Flue Boxes 12.1 Fuel Bed Layout (pebble versions) Unpacking the Appliance 13.0 Fitting Fireframe and Front...
  • Page 4: Appliance Data

    APPLIANCE DATA Manual Control Version Remote Control Version Gas Group G20 Natural Gas CAT I2H G20 Natural Gas CAT I2H Inlet Pressure 20mbar (+/- 2.0mbar) 20mbar (+/- 2.0mbar) Max Energy Input (gross) 6.8kW 6.8kW Min Energy Input (gross) 3.5kW 3.5kW Pilot Energy Input (gross) 166W 166W...
  • Page 5 SITE REQUIREMENTS - continued This appliance requires a natural draught flue system which may be one of the following; 225mm x 225mm (9in x 9in) brick or stone. 175mm (7in) minimum diameter lined brick or stone. 175mm (7in) minimum diameter twin wall flue conforming to BS 715. Any existing under grate draught device must be sealed off.
  • Page 6: Ventilation

    VENTILATION No purpose provided ventilation is normally required for this appliance. The requirements of other appliances operating in the same room or space must be taken into consideration when assessing ventilation. If spillage is detected when commissioning the appliance then amongst other problems there may be insufficient natural ventilation for the correct operation of the flue.
  • Page 7: Unpacking The Appliance

    UNPACKING THE APPLIANCE Stand the carton right way up, cut the strapping bands and remove the top end cap. Read all the instructions before continuing to unpack or install this appliance. Remove the box containing the fire front, and the bags and boxes containing the ceramic parts. Remove the cardboard packing pieces, and any bags containing other fittings or parts.
  • Page 8: Preparing The Opening

    PREPARING THE APPLIANCE - continued Knockout holes are provided in the rear and sides of the firebox for use where concealed pipework is required. Where necessary, knock out the appropriate hole with a sharp tap from a hammer, and fit the rubber grommet supplied. A small incision can now be made in the rubber to slip snugly around the outside of the pipe and sleeving.
  • Page 9: Fitting The Firebox

    10.0 GAS SUPPLY ROUTING (continued) The gas pipe must be suitably protected where it passes through fireplace openings. Any sleev- ing should be sealed to the pipe at its ends. This appliance is fitted with an inlet restictor elbow. The open end of the supply pipe should be sealed temporarily during the installation of the fire- box to prevent the ingress of dirt and dust.
  • Page 10: Gas Connection

    11.2 GAS CONNECTION Refit the burner tray into the firebox, fit the two screws through the locating holes in the tray legs, and tighten. Purge the gas supply thoroughly to remove air and dirt/debris BEFORE connection. Now dis- connect the inlet restrictor elbow from the inlet pipe.
  • Page 11 12.0 FUEL BED LAYOUT (continued) 3. Open the bag of 22 moulded coals. All of the coals are the same. Take five coals and place them as shown. Care should be taken to ensure that the coals bridge the gap between the front coals and the six coal sup- ports at the front of the matrix.
  • Page 12: Fuel Bed Layout (Pebble Versions)

    12.1 FUEL BED LAYOUT Pebble Effect Option 1. Refer back to section 12.0 - Fuel bed layout (coal effect option) and follow steps 1 and 2. The front strips and fuel effect matrix used for pebble effect versions are of the same design as coal effect versions, but have a different surface finish.
  • Page 13: Fitting Fireframe And Front

    12.1 FUEL BED LAYOUT - continued 5. Finally, take the six remaining pebbles and place at the back of the fuel matrix as shown. Once again, the pebbles may be orientated as desired in order to give a realistic effect. Avoid pushing the pebbles down between the sup- ports.
  • Page 14: Operating The Fire (Manual Versions)

    14.1 OPERATING THE FIRE (manual versions) The pilot is visible through the left hand side of the front coal strip. Push in and turn the control knob to the SPARK position, and hold there for a few seconds. Continue turning anti-clockwise through the spark click to the PILOT light position, ensuring the pilot has lit.
  • Page 15: Operating The Fire (Remote Versions)

    14.2 OPERATING THE FIRE (Remote control versions) continued The remote control unit allows operation of the main burner between maximum and pilot only setting. It does not turn the pilot on or off. The remote control handset incorporates an inbuilt safety feature to pre- vent the main burner being activated or turned up accidentally.
  • Page 16: Servicing

    14.6 TESTING FOR SPILLAGE Close all doors and windows to the room containing the appliance. Let the fire run on HIGH for five minutes. Take a smoke match, light it, and using a smoke match tube, hold it at the top edge of the fire opening, 25mm down and 25mm in.
  • Page 17: Dismantling The Burner Tray

    15.0 SERVICING (continued) 7. Check the area behind the firebox for rubble accumulation and remove. If debris is excessive, initiate remedial work on the flue. 8. Check the flue with smoke pellet for correct operation. 9. Re-fit the firebox using new seals where necessary. 10.
  • Page 18: Troubleshooting Guide

    16.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. Pilot lights but then goes out Severe restriction in gas supply, clear obstruction.
  • Page 19: User Instructions

    USER INSTRUCTIONS Contents Page No. Section Important Notes Firefront Clearances to Combustibles Ventilation Operating Instructions Replacing the batteries (remote control versions only) Flue Spillage Monitoring System Cleaning List of Spares IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’...
  • Page 20: Clearances To Combustibles

    FIREFRONT This fire is supplied with a particular style of firefront. Use of the firefront will ensure an adequate airflow under the firebed for the correct functioning of this appliance. Compliance with safety standards cannot be guaranteed if another style of front is used. CLEARANCES TO COMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below.
  • Page 21: Flue Spillage Monitoring System

    OPERATING INSTRUCTIONS (remote control versions) The gas valve has two control knobs ; Turn the main burner control (shown on left hand side of control valve) knob fully anti- clockwise. Turn ignition knob (shown on right hand side of control valve) slightly left towards the igni- tion position until reaching the stop, press down and hold for a few seconds until pilot gas is flowing.
  • Page 22: List Of Spares

    CLEANING (continued) FIREFRAME - The magnetic frame may be removed for cleaning if required. A wipe with a dry cloth is normally sufficient, but on stains it is permissible to use a damp cloth with a mild household cleaner, followed by a wipe with a dry cloth. DO NOT use abrasive cleaners as these may damage the finish.
