installation and user instructions
All instructions must be handed to user for safekeeping
Revision A - 06/09
Country(s) of destination - GB/IE
eko 2030
fuel effect gas fire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eko 2030 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ekofires eko 2030

Summary of Contents for Ekofires eko 2030

  • Page 1 All instructions must be handed to user for safekeeping Revision A - 06/09 Country(s) of destination - GB/IE eko 2030 fuel effect gas fire...
  • Page 2 Eko 2030...

  • Page 3: Installation Instructions

    INSTALLATION INSTRUCTIONS Preliminary Notes Before Installation This appliance is an Inset Live Fuel Effect appliance which provides radiant warmth utilising the latest type burner technology. The fire is designed to fit various types of fireplaces and natural draught flues as listed in the Installation Requirements. The appliance must be installed by a competent person in accordance with Gas Safety (Installation and Use) Regulations 1998.

  • Page 4: Table Of Contents

    Section Page No. Section Contents Contents Page No. Important Notes 10.0 Gas Supply Appliance Data 11.0 Fitting the Firebox Installation Requirements 11.1 Cable Fixing Site Requirements 11.2 Gas Connection 12.0 Fuel Bed Layout Ventilation 13.0 Fireframe and Front Flue Boxes Unpacking the Appliance 14.0 Testing &...

  • Page 5: Appliance Data

    APPLIANCE DATA Manual Control Gas Group G20 Natural Gas CAT I2H Inlet Pressure 20mbar (+/-2.0mbar) Max Energy Input (gross) 6.2kW Min Energy Input (gross) 3.5kW Pilot Energy Input (gross) 166W Setting Pressure (cold) 17.5mbar (+/- 1.5mbar) Main Injector Burner Stereo size 77 Gas Inlet Connection 8mm compression Gas Control Valve...
  • Page 6 SITE REQUIREMENTS (continued) This appliance requires a natural draught flue system which may be one of the following; 225mm x 225mm (9in x 9in) brick or stone. 175mm (7in) minimum diameter lined brick or stone. 175mm (7in) minimum diameter twin wall flue conforming to BS 715. Any existing under grate draught device must be sealed off.

  • Page 7: Ventilation

    VENTILATION No purpose provided ventilation is normally required for this appliance. The requirements of other appli- ances operating in the same room or space must be taken into consideration when assessing ventilation. If spillage is detected when commissioning the appliance then amongst other problems there may be insuf- ficient natural ventilation for the correct operation of the flue.

  • Page 8: Unpacking The Appliance

    UNPACKING THE APPLIANCE Stand the carton right way up, cut the strapping bands and remove the top end cap. Read all the instructions before continuing to unpack or install this appliance. Remove the box containing the fire front, and the bags and boxes containing the ceramic parts. Remove the cardboard packing pieces, and any bags containing other fittings or parts.

  • Page 9: Preparing The Opening

    PREPARING THE OPENING Before installing the fire, check the flue using a smoke pellet. All of the smoke should travel up the flue and exit correctly from the terminal. If problems are found, DO NOT fit the fire until corrective action is com- pleted.

  • Page 10: Fitting The Firebox

    10.0 GAS SUPPLY ROUTING (continued) The gas pipe must be suitably protected where it passes through fireplace openings. An isolator cock or restrictor elbow must be fitted to the incoming supply to facilitate servicing. Any sleeving should be sealed to the pipe at its ends. The open end of the supply pipe should be sealed temporarily during the installa- tion of the firebox to prevent the ingress of dirt and dust.

  • Page 11: Gas Connection

    GAS CONNECTION 11.2 Refit the burner tray into the firebox, fit the two screws through the locating holes in the tray legs, and tight- Purge the gas supply thoroughly to remove air and dirt/debris BEFORE connection. Now disconnect the inlet restrictor elbow from the inlet pipe.

  • Page 12: Spark Failure

    14.2 SPARK FAILURE The gap between the spark electrode and the pilot should be 3.5 - 4.5mm to produce a good spark. There should be no need to adjust this. If under any circumstances the electric spark fails, the pilot may be lit man- ually by proceeding with the ignition sequence as previously described, and after turning the control knob through the spark position, the knob should be held in and the pilot lit with a taper.

  • Page 13: Servicing

    14.5 TESTING FOR SPILLAGE (continued) A . 2 5 m m Fireplace Opening Cross section of smoke match tube down from top of open- B. 25mm in from front of Tube opening. Crimp Match C. Disregard Make a smoke match tube from 10mm outer 50mm diameter tube.

  • Page 14: Dismantling The Burner Tray

    15.1 CLEANING THE CERAMIC FUEL BED Remove the ceramic components. Gently clean in the open air. Be careful not to create dust from the peb- bles. Where necessary replace damaged components with genuine spares. Seal scrap components in plastic bags and dispose of at proper refuse sites as directed. Re-fit the pebbles carefully by referring to the relevant section of these instructions.

  • Page 15: Troubleshooting Guide

    16.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. Pilot lights but then goes out Severe restriction in gas supply, clear obstruction.

  • Page 16: User Instructions

    USER INSTRUCTIONS Section Contents Page No. Important Notes Clearances to Combustibles Ventilation Fuel bed layout Operating Instructions Flue Spillage Monitoring System Cleaning List of Spares IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person (such as a CORGI registered fit- ter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’...
  • Page 17 CLEARANCES TO COMBUSTIBLES (continued) Any combustible side walls must be at least 500mm to the side of the radiant heat source. As with all heating appliances, any decorations, soft furnishings, and wall coverings (i.e. flock, blown vinyl and embossed paper) positioned too close to the appliance may discolour or scorch. VENTILATION No purpose provided ventilation is normally required for this appliance.
  • Page 18 FUEL BED LAYOUT (continued) 5. Place the pebble ‘D’ onto the peg ‘D’ on the matrix as shown. When pebble ‘C’ is in position this pebble can only fit onto the peg one way - do not force it on. 6.

  • Page 19: Operating Instructions

    FUEL BED LAYOUT (continued) 10. Place the pebbles ‘I’ and ‘J’ onto the four large pebbles on the left hand side of the fuel bed as shown. 11. Place the pebbles ‘K’, ‘L’ and ‘M’ onto the four large pebbles on the left hand side of the fuel bed as shown.

  • Page 20: List Of Spares

    CLEANING Before carrying out any of the following operations, ensure that the fire is OFF and completely cold. Debris that may form on the firebed should be periodically removed by a competent person. Large deposits could indicate deterioration of the flue. This should be repaired by a competent person, and the fire serv- iced before further use.
