Managed By Vcm - 3xLogic vigil Client User Manual

Auto Hide Toolbar in Full
Screen Mode
Show Splash Screen on
Startup

13.1.1 Managed by VCM

VIGIL Client can be configured to pull its list of
Servers from a VCM Server. This allows the Servers
list to be up to date with all VIGIL Servers the user
has access to without having to constantly update
the Servers list locally on the Client. Enable the
check box and click the VCM Settings button to open
the VCM Settings window.
When VIGIL Client starts, the user will be prompted to select a VCM Server to con-
nect to and retrieve the VIGIL Server List or choose Local Settings to load the
VIGIL Server list that was locally configured on the VIGIL Client.
-
90-
Enable this option to make the toolbar controls hide until hovered over while VIGIL Client is in Full
Screen Mode. For more information, See "Live Viewer" on page 36 for more info.
When enabled, the VIGIL Client splash screen is automatically displayed when the program is
launched.
Enter a Descriptive Name for the VCM Server, this name
VCM Name will show in the Connection window when Client is
launched.
Enter the IP Address for the system the VCM Server Service
IP Address
is running on.
Enter the Port for the VCM Server Service. The default is
Port
10507.
VCM User Enter a Valid Username and Password that exist on the VCM
Name / Pass- Server. The list of VIGIL Servers provided by the VCM
word Server will be based on the permissions of the VCM User.
Always
Requires user to enter credentials for VCM Server every
Prompt for
time VIGIL Client is launched.
Log On
Click to test that the IP and Port information is correctly
Test IP
configured.
©2014 3xLOGIC Inc. | VIGIL Client - User Guide
