Playback Synchronization Controls

The Synchronize and Unsynchronize button respond differently to left or right click. While left-clicking will simply sync or unsync the
selected playback stream with the current synchronization pool, right-clicking presents the user with an advanced set of Playback
Synchronization Options.
Unsynchronized Camera Options:
Unsync All Playbacks - Unsync all streams currently in
the synchronization pool.
Sync this Playback - Sync this stream with the streams
currently in the synchronization pool
Sync this Playback and Set Camera Timestamp- Sync
this stream with the streams currently in the syn-
chronization pool using the selected streams timestamp
as the principle synchronization timestamp.
Sync All Playbacks- Add all remaining unsynchronized
playback streams to the synchronization pool . This
option will only be available when a principle timestamp
has been configured.
Sync All Playbacks and Set Camera Timestamp- Add all
remaining unsynchronized playback streams to the syn-
chronization pool using the selected streams timestamp
as the principle synchronization timestamp.
Note:
When a stream frame shows the
unsynchronize the feed from other playback feeds. The
button to synchronize the camera into the active synchronization pool. If no pool exists, the pool will be created using this
camera's timestamp as the principal timestamp of the synchronization pool. All cameras added to the synchronization pool
after this point will be synchronized based on the principal camera's timestamp.

Right

Smart Search – Use this to open the Smart Search Toolbox.
To perform a Smart Search, you must first define or "mask" a
motion detection region. To do this, click the Show Mask Button (
) and draw a mask on the playback image. Click the Search
button (
plete, only video frames that contain motion in the masked region
will be loaded for playback. Use the
back/forward to the next Smart Search frame. Click the Reset
Button (
viously loaded footage. You may use the Sensitivity Slider to
select higher or lower levels of motion sensitivity for the Smart
Search Area.
-
76-
button in its edge controls, it is already synchronized. Clicking the button will
) to perform the search. Once the search is com-
) to clear the Smart Search Area and show the pre-
Synchronized Camera Options:
Unsync Playback-Unsynchronize the selected stream from the syn-
chronization pool
Unsync All Playback - Unsync all streams currently in the syn-
chronization pool.
Sync All Playbacks- Add all remaining unsynchronized playback
streams to the synchronization pool . This option will only be avail-
able when a principle timestamp has been configured.
Sync All Playbacks and Set Camera Timestamp- Add all remaining
unsynchronized playback streams to the synchronization pool using
the selected streams timestamp as the principle synchronization
timestamp.
indicates that a camera is currently unsynchronized. Click the
buttons to skip
The Smart Search Toolbox
