Camera Settings Sub-Tab

Brightness
Sharpness
Contrast
Hue
Saturation U/ Saturation V
Noise Reduction

Recording Mode Sub-Tab

The Recording Mode Sub Tab allows for the Recording Speed of the Camera and the Recording Mode to be configured. There are four
Recording Mode options encompassing a full range of recording possibilities. These modes are accessible by selecting the appropriate
option from the Recording Mode drop-down menu.
Opens the Recording Speed window. The recording speed can be
set individually for Constant, Motion and Alarm Recording
Mode. Use the drop-down menu to select the desired number of
frames per second (fps).
Speeds...
©2014 3xLOGIC Inc. | VIGIL Client - User Guide
Adjusts the brightness of the video footage.
Adjusts the sharpness of the video footage
Adjusts the contrast of the video footage.
Adjusts the hue of the video footage.
Adjusts the U and V color difference signals used in YUV color format for the video footage.
Note:
Not all cameras use a YUV color format, in which case, adjusting the Saturation
U slider will adjust the color saturation while the Saturation V slider will have no
effect.
Reduces video noise on grainy video images. Warning: If this value it is set too high it may have
detrimental effects.
Note:
Network cameras will often record and play back
at a slower rate than what was set in the Recording
Speed window, depending on the bandwidth and cam-
era.
