13.11 Virtual Switch Tab

The Virtual Switch tab allows configuration of up to eight digital (PC) or analog monitor outputs.
Disable the Virtual Switch feature.
Disabled
The digital virtual switch feature allows users to configure additional PC monitors to display up to
16 simultaneous live camera feeds per PC monitor. Users are able to access and control all cameras
Digital
from VIGIL Server sites, whether they are analog, network, or PTZ cameras, all without the need
for a KBD300 keyboard.
Config (For Software Mode Only)
Show Timestamp Displays the video time on the monitor output screen.
Displays coloured camera borders that indicated the recording mode on the monitor output screen.
Show Record Status
Blue for motion, yellow for dwell time, green for constant, and red for alarm.
Stretch Image to Fit Win-
Stretches the camera image to fit the virtual switch monitors (i.e. camera spots).
dow
Enable this to automatically play the Priority Audio channel associated with a selected video
Priority Audio
stream when the video stream is added to the virtual switch monitor.
Enable this option to display OSD data on applicable cameras currently displayed on the Virtual
Show OSD
Switch monitor(s).
-
