360 Dewarping
360 Dewarping
(cont'd)
Priority Audio
Analytics
Speed
Video Pre Buffer
Relays
Quick Search
Audio Talk
Sub Stream / Rap-
idStream
©2014 3xLOGIC Inc. | VIGIL Client - User Guide
tings.
This option is available for cameras using the 360 Dewarping control type. This must be configured on
VIGIL Server to be available as an option in Client.
This option is enabled by default. This feature allows users to zoom in and move
Source Video Only
cameras during playback. Click on an area of interest and then use the mouse scroll
(Rotate Disabled)
to zoom in. Click-and-drag to move the image after it is zoomed in.
This feature allows users to zoom in and rotate cameras during playback. Click on
Source Video Only
an area of interest and then use the mouse scroll to zoom in. Or, click-and-drag to
(Rotate enabled)
rotate the image. This option is only available for ceiling mounted 360 cameras.
This feature splits the playback image into 4 quadrants. The first quadrant shows the
full image, and the second, third and fourth quadrants show different zoomed sec-
360 View and
tions of the image. To load an area of interest in one of the zoom quadrants, click
Source Video
on a zoom quadrant and then click on the first quadrant to load that section. The
zoomed sections can be clicked on directly and then rotated.
Panorama View This feature dewarps the 360 camera into an elongated, panorama-style image. A
(Wall-mounted user may digitally pan and zoom in and out of the image for added review capabil-
360 cameras only) ity.
If a Priority Audio channel is configured for the camera on VIGIL Server, toggle this option to play live
audio.
Select which Video Analytics information will be displayed on the live video feed.
Select the display speed for the camera. Options are: Slow (1fps), Medium (5fps), Fast (10fps), Turbo
(20fps) Maximum, and Frame by Frame.
Select the Video Pre Buffer time. Auto Sense will detect and apply the best pre buffer settings. Choose
Disabled to have no Video Pre Buffer applied to the current stream.
Interfaces to the server Relay(s). Relays can be toggled on or off, corresponding to closed and open
states respectively.
Note:
Relays must first be configured on the VIGIL Server to enable this option. See the VIGIL
Server user's guide for more information.
Retrieve recent footage from the camera for preset intervals of one, five, or ten minutes or open the
search menu by selecting Search. All options will open the Search window however the one, five or ten
minute interval options will begin playback of the selected camera and time interval.
Opens the audio talk window. Audio Talk must be configured and associated with the Camera on VIGIL
Server for this option to be available.
Toggle between Main and Sub Stream if the Camera supports a Sub Stream. If the Camera does not sup-
port a Sub Stream, the RapidStream option will be available. RapidStream is CPU intensive on the VIGIL
Server and will be disabled if CPU usage exceeds a defined threshold. See the VIGIL Server Users Guide
for more details.
