Compak E6 OD Instruction Manual page 13

*
NOTE: Changing grind settings must be done when the grinder is on and burrs are in motion.
Not doing this suposes that the burrs will gunk up and cleaning will be required.
* It is recommended that the motor be running when adjusting to finer grind setting.
This helps to avoid jamming the burrs, which can occur when coffee beans are in the
grind chamber, and the grind regulator is adjusted towards fine.
8.3.2. Stepped grind adjustment (optional)
In the stepped adjustment versions, the positions on the grind regulator are limited
by "steps" that are defined by the hole and pin points (Fig. 6).
The instructions detailed in section 8.3.1. on adjusting the regulator should be
followed, while at the same time, pulling the brake post (
locking action of the post.
K06307 | v. 22/07/2015 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
) (Fig. 6) up to release the
11
