Configuring the AXP 64 C AT
After the device is named, use the DSP Configurator to configure the AXP 64 C AT as desired.
Ensure the control computer and AXP 64 C AT are connected to the same network and that the AXP 64 C AT is renamed for
1.
Renaming an AXP 64 C AT
identification (see
Start the DSP Configurator software. From the drop-down list on the opening page, select AXP 64 C AT and press OK.
2.
The main screen opens. The main screen provides access to all the features of the AXP 64 C AT. Full details about using the
software are found in the AXP 64 C AT User Guide on the Extron website or in the DSP Configurator help files.
The program starts in Emulate mode. Select the appropriate operating mode as follows:
3.
To create a configuration offline to upload (push) to the AXP 64 C AT at a
•
later time, keep the AXP in emulate mode.
To push a configuration to the AXP, pull a configuration from the device, or to
•
make immediate changes to the configuration or operation, click the Live
button to place the AXP in Live mode.
NOTE:
Changing from emulate to live mode opens the Connect to
device... dialog box (shown at right). Select the device in the
Dante Devices panel.
On the next dialog box that appears, select the appropriate radio
button to pull data from the selected device to update your
configuration, or to push data from the current configuration to the
selected device, overwriting any existing data.
on page 5).
