5.9 VGA Output Resolution Support

Users are allowed to change the resolution depending on their display monitor.
Right-click to display the main menu, and select "ADVANCED CONFIG"
CAMERA
DETECTION
ALERT
NETWORK
DISPLAY
RECORD
DEVICES
EXIT
Move to "VGA OUTPUT", and select the VGA resolution you want. There are three
options as follows:
1024 x 768 (default)
Note: For the 4CH models, "VGA OUTPUT" appears only when "PRIORITY" is set to
"DISPLAY FIRST". For details, please refer to "4.5 System Sources
Reallocation
Note: To have the best image quality on your LCD monitor, make sure (1) the
selected DVR VGA output resolution is supported by your monitor, and (2)
the VGA output settings on both the LCD monitor and DVR are consistent.
If the image is not positioned or scaled properly, please go to your
monitor's menu for adjustment. For details, please refer to the user manual
of your LCD monitor.
