2.2 Camera Connection

The cameras must be connected and power-supplied before the DVR is powered on.
Connect the camera with the indicated power supply. Then, connect the camera video
output to the DVR video input port with a coaxial cable or RCA cable with BNC
connectors.
Note: For detailed DVR video input ports, please refer to "1.3 Rear Panel" at page
2.

2.2.1 Normal Camera Connection

Note: For detailed camera installation and connection, please refer to its own user
manual.
1) Connecting to DVR video input
Connect the camera video output to the DVR video input port with a coaxial cable or
RCA line with BNC connector.
2) Connecting to DVR audio input (Optional)
Connect the camera audio output to the DVR audio input port with a coaxial cable or
RCA cable with BNC connectors.
3) Connecting to power
Connect the camera with indicated power supply and make sure it's power-supplied.

2.2.2 DCCS Camera Connection

The cameras must be connected and power-supplied before the DVR is powered on.
Connect the camera with the indicated power supply. Then, connect the camera video
output to the DVR video input port with a coaxial cable or RCA cable with BNC
connectors.
Note: Only video channel 1 supports DCCS camera connection.
1) Video cable connection
Connect the camera video output to the DVR video input port with a coaxial cable or
RCA cable with BNC connector.
2) Power connection
Connect the camera with indicated power supply and make sure it's power-supplied.

(For Selected Models Only)

6
CONNECTION AND SETUP
