Avtech avc-798 User Manual page 62

For 8CH Models
Video System
Video Compression Format
Video Input
(composite video signal 1 Vp-p 75Ω BNC)
Video Loop Output
(composite video signal 1 Vp-p 75Ω BNC)
Video Output (BNC)
Video Output (VGA)
Audio Input / Output
Maximum Recording Rate
DCCS Support
Image Quality Setting
Hard Disk Storage**
Quick Search
SATA Interface
Recording Mode
Multiplex Operation
USB Mouse Control
Motion Detection Area
Motion Detection Sensitivity
Pre-alarm Recording
Backup Device
Web Transmitting Compression Format
Ethernet
Remote Surveillance
(Operating System:
Windows 7 / Vista / XP)
Network Protocol
Remote Independent Operation
Remote Live Audio
Remote Event Download & Playback
Event Notification
IR Remote Control
Mobile Surveillance
Picture Zoom
PTZ Control
Alarm I/O
Key Lock (Password Protection)
Local User Level
Main Monitor
Call Monitor
Frame
704×480 pixels with 120 IPS <NTSC> / 704×576 pixels with 100 IPS <PAL>
Field
704x240 pixels with 240 IPS <NTSC> / 704×288 pixels with 200 IPS <PAL>
CIF
352×240 pixels with 480 IPS <NTSC> / 352×288 pixels with 400 IPS <PAL>
Live display / record / playback / backup / network operations
10/100 Base-T. Supports remote control and live view via Ethernet
CMS:
Web Browser:
Media Player:
Max. on-line user:
Model 3
NTSC / PAL (auto detection)
H.264
8 channels
8 channels
For stable display
For sequence display
Built-in (Resolution support up to 1600 x 1200)
4 audio inputs / 2 audio outputs (Mono)
NO
SUPER BEST / BEST / HIGH /NORMAL
2 SATA HDDs
Time / Motion / Alarm search mode
Built-in
Manual / Timer / Motion / Alarm / Remote
YES
16 × 12 grids per camera for all channels
3 adjustable parameters for accurate detection
YES
DVD Writer (Optional) / Flash drive / Network
H.264
Our self-developed and free software,
"Video Viewer"
Internet Explorer, Mozilla Firefox, Google
Chrome, Safari & Opera
QuickTime
10
TCP/IP, PPPOE, DHCP and DDNS
YES
YES
YES
FTP / E-Mail
YES (IR receiver built-in)
YES
2X digital zoom
YES
8 inputs, 1 output
YES
Administrator & Operator
56
APPENDIX 1 SPECIFICATIONS
Model 4
YES
