Page 1: Installation Guide
362Z Installation Guide Intelligent Video Surveillance GUI Display with USB Mouse Control Please read instructions thoroughly before operation and retain it for future reference. For the actual display & operation, please refer to your DVR in hand. 799B_797B_794B_Quick_V0.9... - Page 2 To know more about IVS system and EagleEyes, and where to download EagleEyes, please visit: http://www.eagleeyescctv.com To know more about feature applications, please visit: http://www.eagleeyescctv.com/video To seek for technical support, please contact: support@avtech.com.tw To give us your precious suggestions and comments, please contact: marketing@avtech.com.tw...
-
Page 3: Trademark Acknowledgements
IMPORTANT SAFEGUARD CAUTION RISK OF ELECTRIC SHOCK CAUTION: To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages. - Page 4 GPL Licensing This product contains codes which are developed by Third-Party-Companies and which are subject to the GNU General Public License (“GPL”) or the GNU Lesser Public License (“LGPL”). The GPL Code used in this product is released without warranty and is subject to the copyright of the corresponding author.
-
Page 5: Table Of Contents
TABLE OF CONTENTS 1. PRODUCT OVERVIEW ........................1 2. CONNECTION AND SETUP......................2 2.1 Prerequisites ................................2 2.2 SATA HDD Installation............................2 2.3 Installing DCCS Camera ............................3 2.4 Connecting DCCS Camera ............................3 2.5 DVR Power On ..............................4 2.6 Date and Time Setting............................4 2.7 Clear Hard Disk..............................4 2.8 Password Setting ..............................5 2.9 Examining Signal Transmission ..........................5... -
Page 6: Product Overview
1. PRODUCT OVERVIEW... -
Page 7: Connection And Setup
2. CONNECTION AND SETUP Before the DVR is powered on, make sure you have installed a hard disk, connected at least one camera and a monitor. For details, please refer to the following sections. Note: The DVR is designed to automatically detect the video system of the connected cameras (NTSC or PAL). -
Page 8: Installing Dccs Camera
2-2 To install on the second bracket Connect the power connector and data bus connector to the HDD. When connecting the power cable, make sure the cable is passed through the power cable of DVD writer. This is to prevent the HDD power cable from interfering with the fan spinning. -
Page 9: Dvr Power On
2) Power connection Connect the camera with indicated power supply and make sure it’s power-supplied. 2.5 DVR Power On This device should be operated only with the type of power source indicated on the manufacturer’s label. Connect the indicated AC power cord to the power adapter, and plug into an electrical outlet. The power LED will be on. Note: Before the DVR is powered on, make sure (1) the cameras are connected and power-supplied for the detection of the camera video system to be correct, and (2) a monitor (either LCD or CRT monitor) is connected to the DVR for correct video output detection. -
Page 10: Password Setting
SYSTEM TOOLS BAUD RATE 2400 SYSTEM INFO HOST ID USB BACKUP R.E.T.R DVD BACKUP AUTO KEY LOCK NEVER CLEAR HDD HDD-0 RESET DEFAULT SUBMIT REMOTE CONTROL ID SERIAL TYPE RS485 VIDEO FORMAT NTSC VERSION 1019-1008-1010-1010 EXIT 2.8 Password Setting Right-click to show the main menu, and select “SYSTEM” “TOOLS”... -
Page 11: Configuring Dccs Camera
3) In “CONNECTION”, it shows the examining result for DCCS signal transmission between the DVR and camera. The message is as follows: MESSAGE SHOWN MEANING CHECKING The DVR is checking the DCCS signal transmission between the DVR and camera. The signal transmission is fine and the DCCS function works properly. FAIL The signal transmission is too weak or not available for the DCCS function to work properly. -
Page 12: Gui Display With Usb Mouse Control
3. GUI DISPLAY WITH USB MOUSE CONTROL 3.1 Connect USB Mouse Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( on the screen, indicating the USB mouse is detected properly. Move your mouse to enter the DVR password with the password keypad. -
Page 13: Main Menu
3.3 Main Menu Right-click anywhere on the screen to show the main menu as follows, and right-click again to exit. Main Menu Click to set the status display, image settings, and date & QUICK START time. DATE SETUP Click to set the date display and daylight saving. SYSTEM Click to set the system configurations. - Page 14 ADVANCED CONFIG CAMERA COV. CHANNEL TITLE DETECTION MOTION ALARM AREA ALERT EXT. ALERT INT. BUZZER KEY BUZZER VLOSS BUZZER MOTION BUZZER ALARM BUZZER HDD BUZZER ALARM DURATION (SEC) HDD NEARLY FULL (GB) NETWORK NETWORK SNTP E-MAIL DISPLAY DE-INTERLACE (For AVC799B & 797B Only) FULL SCREEN DURATION QUAD SCREEN DURATION (For AVC799B &...
-
Page 15: Front And Rear Panels
4. FRONT AND REAR PANELS 4.1 Front Panel LED Indicators DVR is powered on. HDD is reading or recording. An alarm is triggered. Timer recording is on. Under playback status. CH1 ~ 16 / 1 ~ 8 / 1 ~ 4 Press the channel number buttons to select the channel to display. -
Page 16: Rear Panel
14) USB port There are two USB ports on the front panel, one for connecting your USB mouse for mouse control, and the other one for connecting your USB flash drive for video backup. Note: It’s not allowed to have two USB mice or two USB flash drives connected on the front panel. Note: For the compatible USB flash drive list, please refer to “APPENDIX 3”... -
Page 17: Basic Operation
5. BASIC OPERATION 5.1 Live Page Icon Function Icon Function Icon Function Live audio channel (1~4) Playback audio channel (1~4) Audio channel off Digital zoom on Digital zoom off Timer recording Network disconnected Internet connected LAN connected USB mouse connected USB flash drive / device connected No USB device connected Key lock... -
Page 18: Playback Control
Note: There must be at least 8192 images of recorded data for playback to work properly. If not, the device will stop playback. For example, if the IPS is set to 30, the recording time should be at least 273 seconds (8192 images / 30 IPS) for the playback to work properly. Note: During playback, the image size of the recording (FRAME, FIELD or CIF) will be shown on the screen. -
Page 19: Vga Output Resolution Support
When the operator password is entered, will be shown on the status bar of the screen, and the main menu is NOT allowed to access. The operator user level needs to be set in the main menu “SYSTEM” “TOOLS”. To switch between these two user levels, click the current user level icon to switch to the key lock mode, and move your mouse to show the password input keypad, and enter the password of the user level you want. -
Page 20: Appendix 1. Set Iphone Push Notification
Note: EagleEyes is a powerful mobile surveillance program developed by AV TECH Corporation. For more operations details about EagleEyes, please visit http://www.eagleeyescctv.com. For any comment or question about this program, please send to support@avtech.com.tw. Your feedback is always welcomed. You need to finish some settings in your iPhone for this function to work properly. For details, please refer to “A1.2.2 Program Setup”... -
Page 21: A1.2.2 Program Setup
STEP3: Read the introduction of the program if needed, and select “INSTALLED” to start the installation. Follow the on-screen instructions to download and install the program. “ ” will be shown on the iPhone desktop for quick access when the program is installed successfully. A1.2.2 Program Setup Step1: Select “EagleEyes”... -
Page 22: A1.2.3 Push Notification On
Column Description Optional Column: Audio Click “>” to select the audio channel you want, and slide to enable or disable the audio function. Note: Before using this function, check whether the camera connected to this DVR supports audio transmission and the connection is correct. For details, please refer to the DVR user manual. -
Page 23: Appendix 2. Set Flow Counting / Virtual Fence / One-Way Pass
APPENDIX 2. SET FLOW COUNTING / VIRTUAL FENCE / ONE-WAY PASS IVS, Intelligent Video Surveillance, is the advanced application for motion detection, but more precise and smarter. It can be applied to different situations with one of the following three modes: FLOW COUNTING, VIRTUAL FENCE, and ONE WAY PASS. -
Page 24: A2.1 Ivs Application
SCENE CHANGE SENSITIVITY Set the detection sensitivity for “SCENE CHANGE” to “HIGH”, “MIDDLE” or “LOW”. A2.1 IVS APPLICATION A2.1.1 FLOW COUNTING Step1: Go to “VIRTUAL FENCE AREA” to draw a detection line with your mouse, and decide the detection direction by selecting “REVERSE”. Step2: Finish the IVS setting and return to the live view. -
Page 25: A2.1.2 Virtual Fence And One Way
A2.1.2 VIRTUAL FENCE and ONE WAY Step1: Go to “VIRTUAL FENCE AREA” to draw a detection line with your mouse, and decide the detection direction by selecting “REVERSE”. Step2: Finish the IVS setting and return to the live view. When anyone walks across the detection line, the system will determine his movement is in or out, and: An event happens for anyone walking across the detection line, and “... -
Page 26: A2.2 Ivs Statistics
A2.2 IVS STATISTICS Click “ ” “ ” to enter the event search menu. Then, select “STATISTIC” LIST QUICK SEARCH CHANNEL RECORD INFLOW EVENT TYPE MOTION OUTFLOW ALARM VIRTUAL FENCE TIME ONE WAY PASS HUMAN DETECTION HUMAN DETECTION MOTION FULL ALARM STATISTIC HARD DISK...
