Avtech avc796 Quick Start Manual

H.264 network dvr
Hide thumbs Also See for avc796:

Advertisement

303Z
H.264 Network DVR

Quick Start

Please read instructions thoroughly before operation and retain it for future reference.
For the actual display & operation, please refer to your DVR in hand.
AC798(D)_797_796(D)_795_792_CD541_Quick_V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the avc796 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Avtech avc796

  • Page 1: Quick Start

    303Z H.264 Network DVR Quick Start Please read instructions thoroughly before operation and retain it for future reference. For the actual display & operation, please refer to your DVR in hand. AC798(D)_797_796(D)_795_792_CD541_Quick_V1.2...
  • Page 2: Front And Rear Panels

    1. FRONT AND REAR PANELS 1.1 Front Panel LED Indicators HDD is reading or recording. DVR is powered on. An alarm is triggered. Timer recording is on. Under playback status (For 4CH model only). HDD is full (For 16CH / 8CH models only). MENU Press “MENU”...
  • Page 3 12) AUDIO (SLOW + ZOOM) Press “SLOW” + “ZOOM” to select live or playback sounds of the audio channels. Live audio of the 1st audio channel Playback audio of the 1st audio channel Live audio of the 2nd audio channel Playback audio of the 2nd audio channel Live audio of the 3rd audio channel Playback audio of the 3rd audio channel...
  • Page 4: Rear Panel

    1.2 Rear Panel 75Ω / HI-IMPEDANCE When using Loop function, please switch to HI-IMPEDANCE. When you don’t use Loop function, please switch to 75Ω. INPUT (1 ~ 16 / 1 ~ 8 / 1 ~ 4): Connect to video sources, such as cameras. LOOP (1 ~ 16 / 1 ~ 8 / 1 ~ 4): Video output connector.
  • Page 5: Basic Operation

    2. BASIC OPERATION 2.1 Live Page In this live page of the DVR, you can see the live viewing of 1- / 4- / 9- / 16-cut screen. Icon Function Icon Function Icon Function Icon Function live audio live audio Key lock Key unlock channel...
  • Page 6: Key Lock And Unlock

    Note: There must be at least 8192 images of recorded data for playback to work properly. If not, the device will stop playback. For example, if the IPS is set to 30, the recording time should be at least 273 seconds (8192 images / 30 IPS) for the playback to work properly. Note: The playback at the local site might not be so smooth if there’s any remote surveillance simultaneously going on.
  • Page 7 2.5 Upgrade ‧ Firmware / Multilanguage OSD Upgrade Use USB to upgrade firmware or OSD Step 1. Format the USB memory device as FAT 32 format first. Step 2. Get the upgrade files from your distributor, and save the upgrade files in your USB flash device (do not change the file name).
