Page 1: User Manual
H.264 Network DVR User Manual GUI Display with USB Mouse Control Please read instructions thoroughly before operation and retain it for future reference. For the actual display & operation, please refer to your DVR in hand. 中文_k679b_677b_674b_c551b_m759b_757b_751b_688b_686b_a791b_Manual_V0.9... -
Page 2: Trademark Acknowledgements
IMPORTANT SAFEGUARD CAUTION RISK OF ELECTRIC SHOCK CAUTION: To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages. - Page 3 Water & Moisture Do not expose this product to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the product. MPEG4 Licensing THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR...
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. BEFORE USING THIS DVR .................1 1.1 Package Content ......................1 1.2 Front Panel ........................1 1.3 Rear Panel ........................2 2. CONNECTION AND SETUP ................4 2.1 SATA HDD Installation....................4 2.2 Camera Connection ..................... 6 2.2.1 Normal Camera Connection ................6 2.2.2 PTZ Camera Connection .......... - Page 5 5.3.3 Alarm Timer ....................... 21 5.4 Detection Setting......................22 5.5 PTZ Camera Setting ....................23 5.6 System Setting......................24 5.6.1 Password Setting....................24 5.6.2 System Upgrade ....................24 5.6.3 Backup & Restore Configurations..............25 5.6.4 Video Backup..................... 25 5.6.5 Clear All HDD Data .................... 27 5.7 Network........................
-
Page 6: Before Using This Dvr
BEFORE USING THIS DVR 1. BEFORE USING THIS DVR 1.1 Package Content Standard Package HDD screws Adapter & Power cord CD Manual Optional Accessories IR Remote Controller USB Mouse Manual for IR Remote Controller DSUB Connector IR Receiver Extension Cable 1.2 Front Panel LED Indicators HDD is reading or recording. -
Page 7: Rear Panel
BEFORE USING THIS DVR SLOW In the playback mode, press to show slow playback. ZOOM Press to enlarge the picture of selected channel in the FRAME or FIELD recording mode. Press to display each channel in full screen one by one starting from CH1. When the last channel is displayed, it will repeat from CH1 again. -
Page 8: Specifications
BEFORE USING THIS DVR VIDEO IN (1 ~ 16 / 1 ~ 8 / 1 ~ 4): Connect to the video connector of a camera. VIDEO LOOP (1 ~ 16 / 1 ~ 8): Video output connector. (For Selected Models Only) Note: The DVR will automatically detect the video system of the camera, please make sure that the cameras are properly connected to the DVR and power-supplied before the DVR is turned on. -
Page 9: Connection And Setup
CONNECTION AND SETUP 2. CONNECTION AND SETUP Before the DVR is powered on, make sure you have installed a hard disk and connected at least one camera. For details, please refer to the following sections. Note: The DVR is designed to automatically detect the video system of the connected cameras (NTSC or PAL). - Page 10 CONNECTION AND SETUP 2-2 To install on the second bracket Connect the power connector and data bus connector to the HDD. When connecting the power cable, make sure the cable is passed through the power cable of DVD writer. This is to prevent the HDD power cable from interfering with the fan spinning.
-
Page 11: Camera Connection
CONNECTION AND SETUP Step4: Align the screw hole on the each bracket with the screw hole on the each side of the HDD as shown below, and fix the HDD to the bracket with a HDD screw supplied. Step5: Close the upper cover of the DVR, and fasten all the screws you loosened in Step 1. 2.2 Camera Connection The cameras must be connected and power-supplied before the DVR is powered on. -
Page 12: Ptz Camera Connection (For Selected Models Only)
CONNECTION AND SETUP 3) Connecting to power Connect the camera with indicated power supply and make sure it’s power-supplied. 2.2.2 PTZ Camera Connection (For Selected Models Only) The following description is taking our brand’s PTZ camera as an example. For DVR setting to control the PTZ camera, please refer to “5.5 PTZ Camera Setting” at page 23. -
Page 13: Dvr Power On
CONNECTION AND SETUP For DVR PIN configuration, please refer to “APPENDIX 6 PIN CONFIGURATION” at page 58. For connection details, please check with your installer. STEP 5: Set the speed dome camera at the DVR side. Go to “ADVANCED CONFIG” “REMOTE”... -
Page 14: Date And Time Setting
CONNECTION AND SETUP 2.4 Date and Time Setting Before operating your DVR, please set the date and time on your DVR FIRST. Note: Please DO NOT change the date or time of your DVR after the recording function is activated. Otherwise, the recorded data will be disordered and you will not be able to find the recorded file to backup by time search. -
Page 15: Password Setting
CONNECTION AND SETUP SYSTEM TOOLS BAUD RATE 2400 SYSTEM INFO HOST ID USB BACKUP R.E.T.R (For Selected Models Only) AUTO KEY LOCK NEVER CLEAR HDD HDD-0 RESET DEFAULT SUBMIT REMOTE CONTROL ID SERIAL TYPE RS485 VIDEO FORMAT NTSC VERSION 1025-1011-1011-1012 EXIT 2.6 Password Setting Right-click to show the main menu, and select “SYSTEM”... -
Page 16: Gui Display With Usb Mouse Control
GUI DISPLAY WITH USB MOUSE CONTROL 3. GUI DISPLAY WITH USB MOUSE CONTROL 3.1 Connect USB Mouse Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( ) on the screen, indicating the USB mouse is detected properly. -
Page 17: Channel Switch
GUI DISPLAY WITH USB MOUSE CONTROL Click to select the audio channel you want: In the live mode, only the live audio channels can be selected. In the playback mode, live and playback audio channels can be selected. Click to enter the PTZ mode and show the PTZ camera control panel. -
Page 18: Main Menu
GUI DISPLAY WITH USB MOUSE CONTROL Click to enter the camera main menu. Camera Menu For details about each camera menu, please refer to its own user manual. Click to confirm your selection / enter the menu. Enter Up / Down / Left / Click to move your selection up / down / left / right, or change settings. -
Page 19: Basic Operation
BASIC OPERATION 4. BASIC OPERATION 4.1 Live Page Icon Function Icon Function Icon Function Playback audio channel Live audio channel (1~4) Audio channel off (1~4) Digital zoom on Digital zoom off Timer recording Network disconnected Internet connected LAN connected USB flash drive / device No USB device USB mouse connected connected... -
Page 20: Playback
BASIC OPERATION 4.3 Playback Click “ ” on the quick menu bar to display the playback control panel, and click play the latest recorded video clip, or click to enter the search list. Note: There must be at least 8192 images of recorded data for playback to work properly. -
Page 21: Event Search
BASIC OPERATION 4.3.2 Event Search Click to quickly search the recorded files by event lists: RECORD / MOTION / ALARM / TIME, or select FULL to show all the event logs. To quickly search the time you want, select “QUICK SEARCH”. Set the time range you want, and select “Start”... -
Page 22: Frequently-Used Functions
FREQUENTLY-USED FUNCTIONS 5. FREQUENTLY-USED FUNCTIONS 5.1 Quick Search Press “LIST” on the DVR front panel to enter the time search menu as follows: EVENT INFORMATION HARD DISK ALL HDD CHANNEL 2009 15 : 20 SUBMIT Step1: Select the hard disk and channel including the video data you want to search. Step2: Select the month including the video data you want to search from the calendar, and the date with recorded data will be highlighted. -
Page 23: Record
FREQUENTLY-USED FUNCTIONS 5.2 Record 5.2.1 Quick record setting Right-click to display the main menu, and select “QUICK START” “GENERAL” “RECORD CONFIGURATION”. Click “SETUP” to enter the setting page individually for manual record, event record and timer record. QUICK START GENERAL CHANNEL TITLE TIME SETUP EVENT STATUS... -
Page 24: Detailed Record Setting
FREQUENTLY-USED FUNCTIONS Note: The allocatable IPS (image per second) in each image size for a DVR is fixed. When allocating IPS to each channel, select “LOCK” to remind you of the remaining IPS in each image size available for the rest of the channels. 5.2.2 Detailed record setting Right-click to display the main menu, and select “ADVANCED CONFIG”... -
Page 25: Schedule Setting
FREQUENTLY-USED FUNCTIONS EVENT RECORD ALL CHANNEL Select to record all channels (ON) or record the channel with an event only (OFF) for any event. KEEP DATA LIMIT (DAYS) Assign the maximum recording days from 01 to 31 after which all the recorded data will be removed, or select “OFF”... -
Page 26: Detection Timer
FREQUENTLY-USED FUNCTIONS 5.3.2 Detection Timer Click “DETECTION”. In “DETECTION TIMER”, select “ON” to enable record timer, and select the day and time for this function. SCHEDULE SETTING RECORD DETECTION TIMER DETECTION ALARM EXIT X axis 0 ~ 24 hours. Each time bar is 20 minutes. Y axis Monday ~ Sunday. -
Page 27: Detection Setting
FREQUENTLY-USED FUNCTIONS 5.4 Detection Setting Right-click to display the main menu, and select “ADVANCED CONFIG” “DETECTION”. ADVANCED CONFIG CANERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 DETECTION ALERT NETWORK DISPLAY DETECT RECORD ALARM REMOTE AREA EDIT EXIT LS (Level of Sensitivity) “LS”... -
Page 28: Ptz Camera Setting
FREQUENTLY-USED FUNCTIONS AREA Click “EDIT” to set the motion detection area. There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being detected while the transparent blocks are the area under detection. -
Page 29: System Setting
FREQUENTLY-USED FUNCTIONS 5.6 System Setting 5.6.1 Password Setting Right-click to display the main menu, and select “SYSTEM” “TOOLS”. SYSTEM TOOLS LANGUAGE ENGLISH SYSTEM INFO ADMIN PASSWORD SETUP USB BACKUP OPERATOR PASSWORD SETUP UPGRADE SUBMIT BACKUP CONFIG SUBMIT RESTORE CONFIG SUBMIT EXIT ADMIN PASSWORD Click “SETUP”... -
Page 30: Backup & Restore Configurations
FREQUENTLY-USED FUNCTIONS Note: Before using the USB flash drive, please use your PC to format the USB flash drive to FAT32 format first. For the list of compatible USB flash drives, please refer to “APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST” at page 5.6.3 Backup &... - Page 31 FREQUENTLY-USED FUNCTIONS SYSTEM TOOLS START DATE 2009/NOV/19 SYSTEM INFO START TIME 08:30:21 USB BACKUP END DATE 2009/NOV/19 DVD BACKUP END TIME 17:59:29 CHANNEL HARD DISK ALL HDD BACKUP SUBMIT REQUIRE SIZE: 554MB SUBMIT EXIT AVAILABLE SIZE: 3788.0MB START DATE / START TIME Select the start date &...
-
Page 32: Clear All Hdd Data
FREQUENTLY-USED FUNCTIONS 5.6.5 Clear All HDD Data Right-click to show the main menu, and select “SYSTEM” “SYSTEM INFO” “CLEAR HDD”. SYSTEM TOOLS BAUD RATE 2400 SYSTEM INFO HOST ID USB BACKUP R.E.T.R. (For Selected Models Only) AUTO KEY LOCK NEVER CLEAR HDD HDD-0 RESET DEFAULT... -
Page 33: Event Notifications
FREQUENTLY-USED FUNCTIONS NETWORK TYPE Select the network type as STATIC and set all the information needed in the DVR. NETWORK INFORMATION (IP / GATEWAY / NETMASK) Key in all the network information obtained from your ISP (Internet Service Provider). DNS (PRIMARY DNS / SECONDARY DNS) Key in the IP address of the domain name server obtained from your ISP (Internet Service Provider). -
Page 34: E-Mail
FREQUENTLY-USED FUNCTIONS 5.8.2 E-MAIL When this function is enabled and an event occurs, a html file including a link will be sent to the specified E-mail address. Click the link to access to this DVR and check the event recording. ADVANCED CONFIG CANERA NETWORK SNTP FTP E-MAIL... -
Page 35: Remote Operation
REMOTE OPERATION 6. REMOTE OPERATION You can also control the DVR remotely via the supplied licensed software “Video Viewer”, Internet Explorer web browser, and Apple’s QuickTime player. 6.1 Supplied Licensed Software The sections below describe frequently-used functions of the Video Viewer. For details about this software and network settings, please download its extended user manual from the following link: http://www.surveillance-download.com/user/CMS.pdf... - Page 36 REMOTE OPERATION control panel. d) Click “ ” “ ” to key in the default IP address, user name, password, and port number of the DVR you intend to connect. Click “ ” “ to search the available IP address(es) of other DVR(s) ”...
-
Page 37: Control Panel Overview
REMOTE OPERATION 6.1.2 Control Panel Overview Two control panels are available and can be switched depending on your use habit. Simplified Version (Default) -
Page 38: Function Description
REMOTE OPERATION Full Function Version Main Button Overview Button Function Description Full Simplified Function Click to show the predefined IP address(es). You Address Book can add, remove or search the IP address to log in the DVR remotely. Remote Click to go into the detailed Config DVR setting. -
Page 39: General Operation
REMOTE OPERATION Button Function Description Full Simplified Function recording of the selected log. Record / Click to start / stop the manual recording. Record Stop Click to take a snapshot of the current view. The Snapshot snapshot will be saved in the path you specified in “Record Setting”. -
Page 40: Network Backup
REMOTE OPERATION ‧Record path If “Manual” is checked, click “ ” or “ ” on the main control panel to start the manual recording immediately, and the recordings will be saved in the specified location. If “Motion” and / or “Alarm” are checked, the recording function will also be enabled at the remote side when any event is triggered at the DVR side, and the recordings will be saved in the specified location. - Page 41 REMOTE OPERATION Function Description HDD Number / Channel Specify the hard disk (HDD Number) and channel number (Channel) within which have the video data you need. Download by Time Specify the time range within which has the video data you want in the “Start Time”...
-
Page 42: Firmware Upgrade
REMOTE OPERATION Firmware Upgrade This function is used to grade your DVR for function scalability. Note: Before using this function, make sure you have the correct upgrade files provided by your installer or distributor. Step1: Click “ ”, and select the IP address of your device in the address book. Step2: Click “... -
Page 43: E-Map
REMOTE OPERATION 6.1.4. E-Map Video Viewer is also a Central Management System (CMS) software, which allows network device control & management for up to 16 devices simultaneously. Note: Before using this function, make sure Video Viewer is connected to all the devices (up to 16) you want to monitor. - Page 44 REMOTE OPERATION...
- Page 45 REMOTE OPERATION STEP3: When the E-Map group is created, you will see the tree on the top-left panel, showing all the devices you’ve added to this group. Icon Description The connected device is camera. When it’s selected, it will become red. The connected device is DVR.
- Page 46 REMOTE OPERATION For Single E-Map Group Right-click on the group name to show the shortcut menu list, and select “Edit E-MAP” or “Remove E-MAP” as needed.
- Page 47 REMOTE OPERATION For Building E-Map Group Right-click on the group name to show the shortcut menu list, and select “Edit Building E-MAP” or “Remove E-MAP” as needed. To edit or remove a certain level of the building E-Map group, right click on the level name, and select “Edit E-MAP”...
-
Page 48: Web Browser
REMOTE OPERATION 6.2 Web Browser You can view the images or operate your DVR with a web browser, such as Internet Explorer, Mozilla Firefox or Google Chrome. Note: The supported PC operation systems are Windows 7, Vista, XP and 2000. Note: To use Mozilla Firefox or Google Chrome for remote access, please go to Apple’s official website (http://www.apple.com/quicktime/win.html) to download and install QuickTime first. - Page 49 REMOTE OPERATION Icon Description Click to go to the live view of the DVR. Click to enter the playback panel where you can search or select the event you want to play and download to your PC simultaneously. For details, please refer to “6.2.1 Event Download &...
-
Page 50: Event Download & Playback
REMOTE OPERATION Icon Description Click to pause the video playback. Click to stop the video playback. Click to play the video clip slowly, once to get 4X slower, twice get 8X slower. Click to open the playback search panel. 6.2.1 Event Download & Playback Close all / Click to close the current playback video clip (in the red frame), or... - Page 51 REMOTE OPERATION Audio Click to mute the playback if necessary, and click again to restore. (For Selected Note: Audio is available when your camera supports audio recording, Models Only) and connects to the video channel which supports audio recording and the audio input of the DVR. For details, please refer to “1.3 Rear Panel”...
-
Page 52: Appendix 1 Specifications
APPENDIX 1 SPECIFICATIONS APPENDIX 1 SPECIFICATIONS For 16CH Models Model 1 Model 2 Model 3 Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 16 channels (composite video signal 1 Vp-p 75Ω BNC) Video Loop Output 16 channels (composite video signal 1 Vp-p 75Ω... - Page 53 APPENDIX 1 SPECIFICATIONS Model 1 Model 2 Model 3 Mobile Surveillance Picture Zoom 2X digital zoom PTZ Control Alarm I/O 16 inputs, 1 output Key Lock (Password Protection) Local User Level Administrator & Operator Video Loss Detection Camera Title Supports up to 12 letters Video Adjustable Hue / Saturation / Contrast / Brightness Date Display Format...
- Page 54 APPENDIX 1 SPECIFICATIONS For 8CH Models Model 4 Model 5 Model 6 Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 8 channels (composite video signal 1 Vp-p 75Ω BNC) Video Loop Output 8 channels (composite video signal 1 Vp-p 75Ω BNC) Video Output (BNC) Main Monitor For stable display...
- Page 55 APPENDIX 1 SPECIFICATIONS Model 4 Model 5 Model 6 Key Lock (Password Protection) Local User Level Administrator & Operator Video Loss Detection Camera Title Supports up to 12 letters Video Adjustable Hue / Saturation / Contrast / Brightness Date Display Format YY/MM/DD, DD/MM/YY &...
- Page 56 APPENDIX 1 SPECIFICATIONS For 4CH Model Model 7 Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 4 channels (composite video signal 1 Vp-p 75Ω BNC) Video Output (BNC) Main Monitor: For stable display Video Output (VGA) Built-in (Resolution support up to 1600 x 1200) Audio Input...
- Page 57 APPENDIX 1 SPECIFICATIONS Model 7 Key Lock (Password Protection) Local User Level Administrator & Operator Video Loss Detection Camera Title Supports up to 12 letters Video Adjustable Hue / Saturation / Contrast / Brightness Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY Daylight Saving Power Source (±10%) DC 19V...
-
Page 58: Appendix 2 Compatible Usb Flash Drive List
APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST Please upgrade the firmware of the DVR to the latest version to ensure the accuracy of the following table. If the USB flash drive is not supported by the DVR, the “USB ERROR” message will be shown on the screen. -
Page 59: Appendix 3 Compatible Sata Hdd List
APPENDIX 3 COMPATIBLE SATA HDD LIST APPENDIX 3 COMPATIBLE SATA HDD LIST Please upgrade the firmware of the DVR to the latest version to ensure the accuracy of the following table. MANUFACTURER MODEL CAPACITY ROTATION Seagate ST3320613AS 320GB 7200 rpm ST33500320AS 500GB 7200 rpm... -
Page 60: Appendix 4 Main Menu Structure
APPENDIX 4 MAIN MENU STRUCTURE APPENDIX 4 MAIN MENU STRUCTURE QUICK START GENERAL CHANNEL TITLE EVENT STATUS DATE DISPLAY RECORD CONFIGURATION TIME SETUP DATE TIME DATE SETUP DATE INFO DISPLAY DATE OF MODE FORMAT DAYLIGHT DAYLIGHT SAVING SYSTEM TOOLS LANGUAGE ADMIN PASSWORD OPERATOR PASSWORD UPGRADE... - Page 61 APPENDIX 4 MAIN MENU STRUCTURE ADVANCED CONFIG DISPLAY DE-INTERLACE (For Selected Models Only) FULL SCREEN DURATION QUAD SCREEN DURATION (For Selected Models Only) DWELL SCREEN DURATION (For Selected Models Only) DISPLAY COVERT HDD DISPLAY MODE VGA OUTPUT ALPHA BLENDING RECORD MANUAL RECORD ENABLE EVENT RECORD ENABLE TIMER RECORD ENABLE...
-
Page 62: Appendix 5 Dvr Battery Replacement
APPENDIX 5 DVR BATTERY REPLACEMENT APPENDIX 5 DVR BATTERY REPLACEMENT DVR time reset after power failure, for example, caused by a power outage, will cause the disorder of the recorded data, and users may have problems in searching the event clip they want. -
Page 63: Appendix 6 Pin Configuration
APPENDIX 6 PIN CONFIGURATION APPENDIX 6 PIN CONFIGURATION ‧ For 16CH Model Siren: When the DVR is triggered by alarm or motion, the COM connects with NO and the siren with strobe starts wailing and flashing. Magnetic Contact: When the magnetic contact is opened, the alarm will be triggered and the recording is on. - Page 64 APPENDIX 6 PIN CONFIGURATION ‧ For 8CH Model Siren: When the DVR is triggered by alarm or motion, the COM connects with NO and the siren with strobe starts wailing and flashing. Magnetic Contact: When the magnetic contact is opened, the alarm will be triggered and the recording is on.
- Page 65 APPENDIX 6 PIN CONFIGURATION ‧ For 4CH Model Siren: When the DVR is triggered by alarm or motion, the COM connects with NO and the siren with strobe starts wailing and flashing. Magnetic Contact: When the magnetic contact is opened, the alarm will be triggered and the recording is on.
-
Page 66: Appendix 7 Dvd Writer Installation
APPENDIX 7 DVD WRITER INSTALLATION APPENDIX 7 DVD WRITER INSTALLATION Some DVR models allow users to install a DVD writer by themselves. To know whether your DVR supports this feature, please check with your local distributor or retailer. The supported DVD writer models are as follows. Please use only the suggested DVD writer models to ensure the compatibility. -
Page 67: Appendix 8 Dvd- / Cd-Rom Compatible List
APPENDIX 8 DVD- / CD-ROM COMPATIBLE LIST APPENDIX 8 DVD- / CD-ROM COMPATIBLE LIST ‧ DVD-ROM List Disc Type Manufacturer Disc MID-TID Code 20X DVD+R RITEK RITEK R05 (rev:och) 16X DVD+R SONY SONY..-D21 TAIYO YUDEN YUDEN000-T03 MITSUBISHI MCC..-004 TDK..-003 MAXELL MAXELL..003 MBIPG101-R05 CMC MAG.-M01... - Page 68 APPENDIX 8 DVD- / CD-ROM COMPATIBLE LIST Disc Type Manufacturer Disc MID-TID Code 6X DVD-RW MITSUBISHI MCC 01RW6X01 JVC1Victord7 RITEK RITEK W06 4X DVD-RW MITSUBISHI MCC 01RW4X TDK601saku RITEK RITEKW04 2X DVD-RW MITSUBISHI MCC 01RW11N9 JVC_VictorW7 TDK502 sakuM3 CMCW02 RITEK RITEK W01 12X DVD-R9 MKM 04 RD30...
