OM POWER OM2000+ Manual page 16

There a re 4 p ossible s ettings f or t he f irst l ine ( one b ar-­‐graph o r t hree p airs o f d ifferent p arameters):
Forward b ar-­‐graph
•
Forward P ower _ R eflected P ower
•
Forward P ower _ S WR
•
Plate v oltage U p _ P late c urrent I p
•
Second and third line are divided to the left and the right side, editable independently. To each of
these p ositions o ne o f t he 1 5 d ifferent p arameters s hould b e s et.
After pressing MENU (S2) S1–S4 buttons
changed their functions. To edit display
parameters, p ress D ISP b utton.
Press D IS1 t o e dit f irst d isplay.
Now you can define parameters for first
three rows. Start with first line, press 1Row
button.
Go UP or DOWN to select desired
parameter. P ress E NT t o c onfirm s election.
If you finish first line settings, press ESC to
go b ack t o t he r ow s election.
To start edit second line, press 2Row
button.
