Manual Color Adjustment

Allows you to mix your own global custom color.
1.) Use the <MODE> button to scroll to Set Run MANUAL, then use the <UP/DOWN>
buttons to display any of Red, Green, Blue, or White settings. Push the <ENTER> button while
highlighting any to display the color intensity range settings from 000 (off) to 255 (100%).
Use the <UP/DOWN> buttons to adjust the intensity, then push <ENTER> to confi rm your
choice.

System Reset

To automatically reset the X/Y motors to automatically realign the moving head position, use the
<MENU> button to scroll to RESET, then push <ENTER>.
DMX Values In-Depth (16/20/116-Channel Mode)
16CH 20CH
CH1 CH1
CH2 CH2
CH3 CH3
CH4 CH4
CH5 CH5
CH6 CH6
BlockHead™ User Manual Rev. B
116CH Channel Value
CH1
000 <--> 020
021 <--> 127
128 <--> 191
192 <--> 255
043
CH2
000 <--> 127
128 <--> 191
192 <--> 255
053
CH3 000 <--> 255
CH4 000 <--> 255
CH5
000 <--> 255
CH6
000 <--> 047
048 <--> 063
064 <--> 079
080 <--> 095
096 <--> 111
112 <--> 127
128 <--> 143
144 <--> 159
160 <--> 175
176 <--> 191
192 <--> 207
208 <--> 223
224 <--> 239
240 <--> 245
246 <--> 255
Page 13
What it does
Pan
No function
Pan Position
Pan Rotate CW Slow <--> Fast
Pan Rotate CCW Slow <--> Fast
Center Default
Tilt
Tilt Position
Tilt Rotate CW Slow <--> Fast
Tilt Rotate CCW Slow <--> Fast
Center Default
Pan Fine
Tilt Fine
Pan, Tilt Speed Adjustment
Track (Fast) <--> Slow
Built-in Programs (images)
No function
1 LED Chase Pattern #1
1 LED Chase Pattern #2
1 LED Chase Pattern #3
2 LED Chase Pattern
3 LED Chase Pattern
4 LED Chase Pattern
Image 1 - Group Pattern - Bars
Image 2 - Group Pattern - Snake
Image 3 - Group Pattern - Square
Image 4 - Group Pattern - Diagonal
Image 5 - Group Pattern - Random Dots
Sound Mode
Sound Mode with Movement
All Programs (ch9 controls speed)
(c) 2014 Blizzard Lighting, LLC
