Figure 1: The BlockHead™ Pin-Up Picture
Head/Arms
Carry Handle
Figure 2: The Rear Connections
DMX In
Power Switch
BlockHead™ User Manual Rev. B
25x CREE® 12w
DMX Out
Fuse Cover
Page 7
RGBW LEDs
4-Button Control
Panel Menu with
LCD Display
Power In
Power Out
(c) 2014 Blizzard Lighting, LLC
