2. MEET THE BLOCKHEAD MOVING HEAD™

MAIN FEATURES:

• 5x5 pixel matrix moving head w/25x CREE® 12w RGBW LEDs
• Infi nite pan and tilt
• 3-phase pan/tilt motors with 16-bit resolution
• User selectable 16/20/116-channel DMX modes
• Individually controllable 4-in-1 LED pixels via 116ch DMX
• Full RGBW color in standalone & DMX mode
• Display built-in numbers, letters, and graphic effects
• 3 degree beam, 5 degree fi eld angle
• Built-in sound active programs
• Built-in automated programs via master/slave
• Built-in sound activated programs via master/slave
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors

CONTROL:

• USITT DMX-512 (16/20/116 channels)
• 3-pin Input/Output
• 4-button menu with LCD display
DMX Quick Reference (16-Channel Mode)
Channel What is does
1 Pan
2 Tilt
3 Pan Fine
4 Tilt Fine
5 Pan/Tilt Speed (slow <--> fast)
6 Built-in Programs (images)
7 Built-in Programs (numbers & symbols)
8 Built-in Programs (letters)
9 Built-in Program Speed (slow <--> fast)
10 Strobe (slow <--> fast)
11 Dimmer (0% <--> 100%)
12 Global Red Intensty (0% <--> 100%)
13 Global Green Intensty (0% <--> 100%)
14 Global Blue Intensty (0% <--> 100%)
15 Global White Intensty (0% <--> 100%)
16 Motor Reset (253-255)
BlockHead™ User Manual Rev. B
Page 5
(c) 2014 Blizzard Lighting, LLC
