Blizzard Lighting blockhead Manual page 15

DMX Values In-Depth (16/20/116-Channel Mode, continued)
16CH 20CH
CH11 CH11 CH11
CH12 CH12 CH12
CH13 CH13 CH13
CH14 CH14 CH14
CH15 CH15 CH15
--- ---
CH16
LED
Row 1
CH17
LED
Row 2
CH18
LED
Row 3
CH19
LED
Row 4
CH20
LED
Row 5
CH16 ---
116-Channel Mode, Channels 16-116
Channels 16-115 in 116 channel mode allows you to adjust the R/G/B/W intensity level from 0-100% for
each individual LED. Pan and tilt motor reset is activated on channel 116, between values 253-255.
CH. LED CH. LED
16 1R 28 4R
17 1G 29 4G
18 1B 30 4B
19 1W 31 4W
20 2R 32 5R
21 2G 33 5G
22 2B 34 5B
23 2W 35 5W
24 3R 36 6R
25 3G 37 6G
26 3B 38 6B
27 3W 39 6W
BlockHead™ User Manual Rev. B
116CH Channel Value
000 <--> 255
000 <--> 255
000 <--> 255
000 <--> 255
000 <--> 255
000 <--> 007
008 <--> 015
016 <--> 023
024 <--> 031
032 <--> 039
040 <--> 047
048 <--> 055
056 <--> 063
064 <--> 071
072 <--> 079
080 <--> 087
088 <--> 095
096 <--> 103
104 <--> 111
112 <--> 119
120 <--> 127
128 <--> 135
136 <--> 143
144 <--> 151
152 <--> 159
160 <--> 167
168 <--> 175
176 <--> 183
184 <--> 191
192 <--> 199
200 <--> 207
208 <--> 215
216 <--> 223
224 <--> 231
232 <--> 239
240 <--> 247
248 <--> 255
000 <--> 252
See Table
Below 253 <--> 255
CH. LED CH. LED CH.
40 7R 52 10R 64
41 7G 53 10G 65
42 7B 54 10B 66
43 7W 55 10W 67
44 8R 56 11R 68
45 8G 57 11G 69
46 8B 58 11B 70
47 8W 59 11W 71
48 9R 60 12R 72
49 9G 61 12G 73
50 9B 62 12B 74
51 9W 63 12W 75
Page 15
What it does
Dimmer (0% <--> 100%)
Global Red Intensity (0% <--> 100%)
Global Green Intensity (0% <--> 100%)
Global Blue Intensity (0% <--> 100%)
Global White Intensity (0% <--> 100%)
LED Row Pixel Control
LED 1 + 2 + 3 + 4 + 5 ON
LED 1 ON
LED 2 ON
LED 1 + 2 ON
LED 3 ON
LED 1 + 3 ON
LED 2 + 3 ON
LED 1 + 2 + 3 ON
LED 4 ON
LED 1 + 4 ON
LED 2 + 4 ON
LED 1 + 2 + 4 ON
LED 3 + 4 ON
LED 1 + 3 + 4 ON
LED 2 + 3 + 4 ON
LED 1 + 2 + 3 + 4 ON
LED 5 ON
LED 1 + 5 ON
LED 2 + 5 ON
LED 1 + 2 + 5 ON
LED 3 + 5 ON
LED 1 + 3 + 5 ON
LED 2 + 3 + 5 ON
LED 1 + 2 + 3 + 5 ON
LED 4 + 5 ON
LED 1 + 4 + 5 ON
LED 2 + 4 + 5 ON
LED 1 + 2 + 4 + 5 ON
LED 3 + 4 + 5 ON
LED 1 + 3 + 4 + 5 ON
LED 2 + 3 + 4 + 5 ON
ROW - ALL OFF
No Function
Fixture Motor Reset
LED CH. LED CH. LED
13R 76 16R 88 19R
13G 77 16G 89 19G
13B 78 16B 90 19B
13W 79 16W 91 19W
14R 80 17R 92 20R
14G 81 17G 93 20G
14B 82 17B 94 20B
14W 83 17W 95 20W
15R 84 18R 96 21R
15G 85 18G 97 21G
15B 86 18B 98 21B
15W 87 18W 99 21W
(c) 2014 Blizzard Lighting, LLC
CH. LED CH. LED
100 22R 112 25R
101 22G 113 25G
102 22B 114 25B
103 22W 115 25W
104 23R
105 23G
Ch. 116
106 23B
107 23W
Reset
Motor
108 24R
109 24G
(253-255)
110 24B
111 24W
