Blizzard Lighting blockhead Manual page 6

DMX Quick Reference (20/116-Channel Modes)
20-CH What is does
1 Pan
2 Tilt
3 Pan Fine
4 Tilt Fine
5 Pan/Tilt Speed (slow <--> fast)
6 Built-in Programs (images)
7 Built-in Programs (numbers & symbols)
8 Built-in Programs (letters)
9 Built-in Program Speed (slow <--> fast)
10 Strobe (slow <--> fast)
11 Dimmer (0% <--> 100%)
12 Global Red Intensty (0% <--> 100%)
13 Global Green Intensty (0% <--> 100%)
14 Global Blue Intensty (0% <--> 100%)
15 Global White Intensty (0% <--> 100%)
16 LED Row 1 Pixel Control
17 LED Row 2 Pixel Control
18 LED Row 3 Pixel Control
19 LED Row 4 Pixel Control
20 LED Row 5 Pixel Control
21 ---
22 ---
23 ---
24 ---
25 ---
26 ---
27 ---
28 ---
29 ---
30 ---
31 ---
32 ---
BlockHead™ User Manual Rev. B
116-CH What is does
1 Pan
2 Tilt
3 Pan Fine
4 Tilt Fine
5 Pan/Tilt Speed (slow <--> fast)
6 Built-in Programs (images)
7 Built-in Programs (numbers & symbols)
8 Built-in Programs (letters)
9 Built-in Program Speed (slow <--> fast)
10 Strobe (slow <--> fast)
11 Dimmer (0% <--> 100%)
12 Global Red Intensty (0% <--> 100%)
13 Global Green Intensty (0% <--> 100%)
14 Global Blue Intensty (0% <--> 100%)
15 Global White Intensty (0% <--> 100%)
16 LED 1 - Red Intensity
17 LED 1 - Green Intensity (0% <--> 100%)
18 LED 1 - Blue Intensity (0% <--> 100%)
19 LED 1 - White Intensity (0% <--> 100%)
20 LED 2 - Red Intensity (0% <--> 100%)
21 LED 2 - Green Intensity (0% <--> 100%)
22 LED 2 - Blue Intensity (0% <--> 100%)
23 LED 2 - White Intensity (0% <--> 100%)
24 LED 3 - Red Intensity (0% <--> 100%)
25 LED 3 - Green Intensity (0% <--> 100%)
--- ---
111 LED 24 - White Intensity (0% <--> 100%)
112 LED 25 - Red Intensity (0% <--> 100%)
113 LED 25 - Green Intensity (0% <--> 100%)
114 LED 25 - Blue Intensity (0% <--> 100%)
115 LED 25 - White Intensity (0% <--> 100%)
116 Motor Reset (253-255)
