5.5.2 DETECTION

CANERA
DETECTION
ALERT
NETWORK
SNTP
DISPLAY
RECORD
REMOTE
DCCS
EXIT
1) LS (Level of Sensitivity)
"LS" is to set the sensitivity of comparing two different images. The smaller the value is, the higher sensitivity
for motion detection. The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default
value is 07.
2) SS (Spatial Sensitivity)
"SS" is to set the sensitivity for detecting the size of one object (the number of the grids) on the screen. The
smaller the value is, the higher sensitivity for motion detection.
The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default setting is 03.
Note: The default setting of SS is 03, which means once an object is detected more than 3 grids, the
system will get triggered. So the value of SS must be less than the number of grids that you set
up for the motion detection area.
3) TS (Time of Sensitivity)
"TS" is to set the sensitivity regarding how long one object stays in the detection area and triggers the
recording. The smaller the value is, the higher sensitivity for motion detection.
The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default setting is 02.
4) DET
Select if you want to activate the motion detection function for the selected channel (ON/OFF).
5) ALARM
Select N.C./ N.O depending on your installation need. The default alarm value is OFF.
6) AREA
Click "EDIT" to set the motion detection area.
There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being
detected while the transparent blocks are the area under detection.
