5.5.6 DISPLAY

CAMERA
DETECTION
ALERT
NETWORK
SNTP
DISPLAY

RECORD

REMOTE
DCCS
EXIT
1) SCREEN DWELL DURATION
Select the full screen dwell duration time in second (3 / 5 / 10 / 15).
2) VGA OUTPUT
Here shows the current VGA output resolution.
3) DISPLAY COVERT
Select "ON" or "OFF" to display or hide the wording "COV." when covert recording is activated in "CAMERA".
4) HDD DISPLAY MODE
Select "SIZE" to show the remaining HDD capacity for recording in GB, or "TIME" to show the remaining
recording time.
5) DISPLAY OUTPUT PATH
The default video output setting is "AUTO", meaning the DVR will automatically detect the video output
source. When a CRT monitor and LCD monitor are both connected, the default video output is via the
connected LCD monitor.
Select "VGA" to fix the video output via the connected LCD monitor, or "COMPOSITE" to fix the video output
via the connected CRT monitor.
When the change is made, the DVR will then reboot for the change to take effect.
6) ALPHA BLENDING
Click to manually adjust the transparent level of the main menu.
5.5.7 RECORD
Note: Please DO NOT change the date or time of your DVR after the recording function is activated.
Otherwise, the recorded data will be disordered and you will not be able to find the recorded file
to backup by time search. If users change the date or time accidentally when the recording
function is activated, it's recommended to clear all HDD data, and start recording again.
riasztobolt.hu
CAMERA
DETECTION
ALERT
NETWORK
SNTP
DISPLAY
RECORD
REMOTE
DCCS
EXIT
ADVANCE CONFIG
SCREEN DWELL DURATION
VGA OUTPUT
DISPLAY COVERT
HDD DISPLAY MODE
DISPLAY OUTPUT PATH
ALPHA BLENDING
ADVANCE CONFIG
MANUAL RECORD ENABLE
EVENT RECORD ENABLE
TIMER RECORD ENABLE
EVENT RECORD IPS
TIMER RECORD IPS
PRE-ALARM RECORD
OVERWRITE
EVENT RECORD ALL CHANNEL
KEEP DATA LIMIT (DAYS)
03
1024 X 768
ON
HDD SIZE
AUTO
200
ON
ON
ON
120
120
ON
ON
OFF
OFF
23
