3. GUI DISPLAY WITH USB MOUSE CONTROL

3.1 Connect USB Mouse

Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there's a mouse icon (
on the screen, indicating the USB mouse is detected properly.
Move your mouse to enter the DVR password with the password keypad. The default administrator password is
0000. The status will be changed from
the left side of the screen.
Note: There are two user levels for DVR access which can be set in the main menu "SYSTEM"
For details, please refer to "5.3.1 TOOLS" at page 15.
Password Input

3.2 Quick Menu Bar

Move to the arrow mark to extend the quick menu bar and show the five functions as follows:
Quick Menu: Open

3.2.1 Channel Switch

riasztobolt.hu
Click on the quick menu bar to display the panel as follows:
(key lock) to
Quick Menu: Close
(administrator), and the quick menu bar appears on
Click to show the channel switch panel and select the channel you want.
For details, please refer to "3.2.1 Channel Switch" at page 8.
Click to display the playback control panel, and click
recorded video clip, or click
please refer to "4.3 Playback" at page 10.
Switch to the channel you want first, and click
mode. In this mode, click and drag the red frame on the bottom left of the
screen to move to the place you want to see. To exit this mode, click
Click to select the audio channel you want:
In the live mode, only the live audio channels can be selected.
In the playback mode, live and playback audio channels can be selected.
Click to enter the PTZ mode and show the PTZ camera control panel. For
details, please refer to "3.2.2 PTZ Control Panel" at page 9.
8
to play the latest
to enter the search list. For details,
to enter the zoom-in
)
"TOOLS".
.
