Avtech DR163 User Manual

H.264 network dvr/ gui display with usb mouse control
Hide thumbs
Table of Contents

Advertisement

Quick Links

395Z
H.264 Network DVR

User Manual

GUI Display with USB Mouse Control

Please read instructions thoroughly before operation and retain it for future reference.
For the actual display & operation, please refer to your DVR in hand.
k679b_677b_674b_675c_c551b_m759b_757b_751b_a791b_Manual_V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR163 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avtech DR163

Summary of Contents for Avtech DR163

  • Page 1: User Manual

    395Z H.264 Network DVR User Manual GUI Display with USB Mouse Control Please read instructions thoroughly before operation and retain it for future reference. For the actual display & operation, please refer to your DVR in hand. k679b_677b_674b_675c_c551b_m759b_757b_751b_a791b_Manual_V1.2...

  • Page 2: Trademark Acknowledgements

    395Z IMPORTANT SAFEGUARD CAUTION RISK OF ELECTRIC SHOCK CAUTION: To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages.
  • Page 3 395Z Grounding This is a Safety Class 1 Product (provided with a protective earthing ground incorporated in the power cord). The mains plug shall only be inserted in a socket outlet provided with a protective earth contact. Any interruption of the protective conductor inside or outside of the instrument is likely to make the instrument dangerous.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1. BEFORE USING THIS DVR ................. 1 1.1 Package Content ......................1 1.2 Front Panel ........................1 1.3 Rear Panel ........................2 2. CONNECTION AND SETUP ................ 4 2.1 SATA HDD Installation ....................4 2.2 Camera Connection ..................... 6 2.2.1 Normal Camera Connection ................
  • Page 5 5.3.3 Alarm Timer ....................... 22 5.4 Detection Setting ......................23 5.5 PTZ Camera Setting ....................24 5.6 System Setting ......................25 5.6.1 Password Setting ....................25 5.6.2 System Upgrade ....................25 5.6.3 Backup & Restore Configurations ..............26 5.6.4 Video Backup ..................... 26 5.6.5 Event Log Backup ....................

  • Page 6: Before Using This Dvr

    BEFORE USING THIS DVR 1. BEFORE USING THIS DVR 1.1 Package Content  Standard Package  DVR  HDD screws  Adapter & Power cord  CD Manual  Optional Accessories  IR Remote Controller  USB Mouse  Manual for IR Remote Controller ...

  • Page 7: Rear Panel

    BEFORE USING THIS DVR SLOW In the playback mode, press to show slow playback. ZOOM Press to enlarge the picture of selected channel in the FRAME or FIELD recording mode. Press to display each channel in full screen one by one starting from CH1. When the last channel is displayed, it will repeat from CH1 again.
  • Page 8 BEFORE USING THIS DVR VIDEO IN (1 ~ 16 / 1 ~ 8 / 1 ~ 4): Connect to the video connector of a camera. Note: The DVR will automatically detect the video system of the camera, please make sure that the cameras are properly connected to the DVR and power-supplied before the DVR is turned on.

  • Page 9: Connection And Setup

    CONNECTION AND SETUP 2. CONNECTION AND SETUP Before the DVR is powered on, make sure you have installed a hard disk and connected at least one camera. For details, please refer to the following sections. Note: The DVR is designed to automatically detect the video system of the connected cameras (NTSC or PAL).
  • Page 10 CONNECTION AND SETUP 2-2 To install on the second bracket Connect the power connector and data bus connector to the HDD. When connecting the power cable, make sure the cable is passed through the power cable of DVD writer if your DVR is equipped with a DVD writer.

  • Page 11: Camera Connection

    CONNECTION AND SETUP Step4: Align the screw hole on the each bracket with the screw hole on the each side of the HDD as shown below, and fix the HDD to the bracket with a HDD screw supplied. Step5: Close the upper cover of the DVR, and fasten all the screws you loosened in Step 1. 2.2 Camera Connection The cameras must be connected and power-supplied before the DVR is powered on.

  • Page 12: Ptz Camera Connection (For Selected Models Only)

    CONNECTION AND SETUP 3) Connecting to power Connect the camera with indicated power supply and make sure it’s power-supplied. 2.2.2 PTZ Camera Connection (For Selected Models Only) The following description is taking our brand’s PTZ camera as an example. For DVR setting to control the PTZ camera, please refer to “5.5 PTZ Camera Setting” at page 24.

  • Page 13: Dvr Power On

    CONNECTION AND SETUP For DVR PIN configuration, please refer to “APPENDIX 6 PIN CONFIGURATION” at page 62. For connection details, please check with your installer. STEP 5: Set the speed dome camera at the DVR side. Go to “ADVANCED CONFIG”  “DEVICES” to set the speed dome camera. a) Select the device to “PTZ”.

  • Page 14: Date And Time Setting

    CONNECTION AND SETUP 2.4 Date and Time Setting Before operating your DVR, please set the date and time on your DVR FIRST. Note: Please DO NOT change the date or time of your DVR after the recording function is activated. Otherwise, the recorded data will be disordered and you will not be able to find the recorded file to backup by time search.

  • Page 15: Password Setting

    CONNECTION AND SETUP SYSTEM TOOLS BAUD RATE 2400 SYSTEM INFO HOST ID BACKUP DATA (USB) AUTO KEY LOCK NEVER BACKUP LOG (USB) CLEAR HDD HDD-0 RESET DEFAULT SUBMIT REMOTE CONTROL ID SERIAL TYPE RS485 VIDEO FORMAT NTSC VERSION 1025-1011-1011-1012 EXIT 2.6 Password Setting Right-click to show the main menu, and select “SYSTEM”...

  • Page 16: Gui Display With Usb Mouse Control

    GUI DISPLAY WITH USB MOUSE CONTROL 3. GUI DISPLAY WITH USB MOUSE CONTROL 3.1 Connect USB Mouse Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( ) on the screen, indicating the USB mouse is detected properly.

  • Page 17: Channel Switch

    GUI DISPLAY WITH USB MOUSE CONTROL Click to select the audio channel you want: In the live mode, only the live audio channels can be selected. In the playback mode, live and playback audio channels can be selected. Click to enter the PTZ mode and show the PTZ camera control panel.

  • Page 18: Main Menu

    GUI DISPLAY WITH USB MOUSE CONTROL Click to enter the camera main menu. Camera Menu For details about each camera menu, please refer to its own user manual. Click to confirm your selection / enter the menu. Enter Up / Down / Left / Click to move your selection up / down / left / right, or change settings.

  • Page 19: Basic Operation

    BASIC OPERATION 4. BASIC OPERATION 4.1 Live Page Icon Function Icon Function Icon Function Playback audio channel Live audio channel (1~4) Audio channel off (1~4) Digital zoom on Digital zoom off Timer recording Network disconnected Internet connected LAN connected USB flash drive / device No USB device USB mouse connected connected...

  • Page 20: Playback

    BASIC OPERATION 4.3 Playback Click “ ” on the quick menu bar to display the playback control panel, and click play the latest recorded video clip, or click to enter the search list. Note: There must be at least 8192 images of recorded data for playback to work properly.

  • Page 21: Event Search

    BASIC OPERATION 4.3.2 Event Search Click to quickly search the recorded files by event lists: RECORD / MOTION / ALARM / TIME, or select FULL to show all the event logs. To quickly search the time you want, select “QUICK SEARCH”. Set the time range you want, and select “SUBMIT”...
  • Page 22 BASIC OPERATION QUICK START GENERAL CHANNEL TITLE TIME SETUP EVENT STATUS DATE DISPLAY MOUSE SENSITIVITY - ‫+ ׀ ׀ ׀ ׀ ׀ ׀ ׀ ׀ ׀‬ PRIORITY RECORD FIRST RECORD CONFIG SETUP EXIT RECORD FIRST: When this option is selected, Full D1 at real-time record on all channels is available, and the VGA output resolution is fixed to 1024 x 768.

  • Page 23: Frequently-Used Functions

    FREQUENTLY-USED FUNCTIONS 5. FREQUENTLY-USED FUNCTIONS 5.1 Quick Search Press “LIST” on the DVR front panel to enter the time search menu as follows: EVENT INFORMATION HARD DISK ALL HDD CHANNEL  01  02  03  04  05  06  07  08 ...

  • Page 24: Record

    FREQUENTLY-USED FUNCTIONS 5.2 Record 5.2.1 Quick record setting Right-click to display the main menu, and select “QUICK START”  “GENERAL”  “RECORD CONFIGURATION”. Click “SETUP” to enter the setting page individually for manual record, event record and timer record. QUICK START GENERAL CHANNEL TITLE TIME SETUP...

  • Page 25: Detailed Record Setting

    FREQUENTLY-USED FUNCTIONS 5.2.2 Detailed record setting Right-click to display the main menu, and select “ADVANCED CONFIG”  “RECORD”. Note: Please DO NOT change the date or time of your DVR after the recording function is activated. Otherwise, the recorded data will be disordered and you will not be able to find the recorded file to backup by time search.

  • Page 26: Schedule Setting

    FREQUENTLY-USED FUNCTIONS KEEP DATA LIMIT (DAYS) Assign the maximum recording days from 01 to 31 after which all the recorded data will be removed, or select “OFF” to disable this function. RECORD CONFIG Please refer to “5.2.1 Quick record setting”. 5.3 Schedule Setting Right-click to display the main menu, and select “SCHEDULE SETTING”.

  • Page 27: Detection Timer

    FREQUENTLY-USED FUNCTIONS 5.3.2 Detection Timer Click “DETECTION”. In “DETECTION TIMER”, select “ON” to enable record timer, and select the day and time for this function. SCHEDULE SETTING RECORD DETECTION TIMER DETECTION ALARM EXIT X axis: 0 ~ 24 hours. Each time bar is 30 minutes. Y axis: Monday ~ Sunday.

  • Page 28: Detection Setting

    FREQUENTLY-USED FUNCTIONS 5.4 Detection Setting Right-click to display the main menu, and select “ADVANCED CONFIG”  “DETECTION”. ADVANCED CONFIG CAMERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11   DETECTION ALERT NETWORK DISPLAY MOTION RECORD ALARM DEVICES AREA EDIT...

  • Page 29: Ptz Camera Setting

    FREQUENTLY-USED FUNCTIONS AREA Click “EDIT” to set the motion detection area. There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being detected while the transparent blocks are the area under detection.

  • Page 30: System Setting

    FREQUENTLY-USED FUNCTIONS 5.6 System Setting 5.6.1 Password Setting Right-click to display the main menu, and select “SYSTEM”  “TOOLS”. SYSTEM TOOLS LANGUAGE ENGLISH SYSTEM INFO ADMIN PASSWORD SETUP BACKUP DATA (USB) OPERATOR PASSWORD SETUP BACKUP LOG (USB) UPGRADE SUBMIT BACKUP CONFIG SUBMIT RESTORE CONFIG SUBMIT...

  • Page 31: Backup & Restore Configurations

    FREQUENTLY-USED FUNCTIONS Note: Before using the USB flash drive, please use your PC to format the USB flash drive to FAT32 format first. For the list of compatible USB flash drives, please refer to “APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST” at page 5.6.3 Backup &...
  • Page 32 FREQUENTLY-USED FUNCTIONS SYSTEM TOOLS START DATE 2009/NOV/19 SYSTEM INFO START TIME 08:30:21 BACKUP DATA (USB) END DATE 2009/NOV/19 BACKUP (DVD) END TIME 17:59:29 BACKUP LOG (USB) CHANNEL  01  02  03  04  05  06  07  08 ...

  • Page 33: Event Log Backup

    FREQUENTLY-USED FUNCTIONS 5.6.5 Record Log Backup Right-click to display the main menu, and select “SYSTEM”  “BACKUP LOG (USB)” This function is used to backup the record log list. Insert a compatible USB flash drive to the USB port at the front panel. Note: Before using the USB flash drive, please use your PC to format the USB flash drive to FAT32 format first.

  • Page 34: Clear All Hdd Data

    FREQUENTLY-USED FUNCTIONS 5.6.6 Clear All HDD Data Right-click to show the main menu, and select “SYSTEM”  “SYSTEM INFO”  “CLEAR HDD”. SYSTEM TOOLS BAUD RATE 2400 SYSTEM INFO HOST ID BACKUP DATA (USB) AUTO KEY LOCK NEVER BACKUP LOG (USB) CLEAR HDD HDD-0 RESET DEFAULT...

  • Page 35: Pppoe

    FREQUENTLY-USED FUNCTIONS DNS (PRIMARY DNS / SECONDARY DNS) Key in the IP address of the domain name server obtained from your ISP (Internet Service Provider). PORT The valid number ranges from 1 to 9999. The default value is 80. Typically, the TCP port used by HTTP is 80.

  • Page 36: Dhcp

    FREQUENTLY-USED FUNCTIONS 5.7.3 DHCP Note: When DHCP configuration is completed, please move to “DDNS” to configure the DDNS service. ADVANCED CONFIG CANERA NETWORK SNTP FTP E-MAIL DDNS DETECTION NETWORK TYPE DHCP ALERT 192.168.001.010 NETWORK GATEWAY 192.168.001.254 DISPLAY NETMASK 255.255.255.000 RECORD PRIMARY DNS 168.095.001.001 DEVICES...

  • Page 37: Event Notifications

    FREQUENTLY-USED FUNCTIONS Note: If you want to additionally apply a DDNS service instead of using ours, please refer to http://www.surveillance-download.com/user/CMS.pdf and check “Appendix 2” for details. ADVANCED CONFIG CANERA NETWORK SNTP FTP E-MAIL DDNS DETECTION DDNS ALERT SYSTEM NAME default NETWORK HOST NAME MAC000E5318B3F0...

  • Page 38: E-Mail

    FREQUENTLY-USED FUNCTIONS 5.8.2 E-MAIL When this function is enabled and an event occurs, a html file including a link will be sent to the specified E-mail address. Click the link to access to this DVR and check the event recording. ADVANCED CONFIG CAMERA NETWORK SNTP FTP E-MAIL...
  • Page 39 FREQUENTLY-USED FUNCTIONS 5.10 System Sources Reallocation (For Selected Models Only) This function is used to reallocate the system sources to live display & record. There are two options for this function: RECORD FIRST / DISPLAY FIRST. QUICK START GENERAL CHANNEL TITLE TIME SETUP EVENT STATUS DATE DISPLAY...

  • Page 40: Remote Operation

    REMOTE OPERATION 6. REMOTE OPERATION You can also control the DVR remotely via the supplied licensed software “Video Viewer”, Internet Explorer web browser, and Apple’s QuickTime player. Note: For more details about mobile surveillance via your smart phones, please visit our official website www.eagleeyescctv.com, or download the instructions of EagleEyes installation and configuration from www.surveillance-download.com/user/eagleeyes_quick.pdf.
  • Page 41 REMOTE OPERATION b) Set the PC’s IP address as “192.168.1.XXX” (1~255, except 10) in order to make the PC and DVR under the same domain. c) Double-click “ ” icon on your PC desktop to enter the control panel. By defaults, the “Address Book”...

  • Page 42: Control Panel Overview

    REMOTE OPERATION 6.1.2 Control Panel Overview Two control panels are available and can be switched depending on your use habit. Simplified Version (Default)
  • Page 43 REMOTE OPERATION Full Function Version Main Button Overview Button Function Description Full Simplified Function Click to show the predefined IP address(es). You Address Book can add, remove or search the IP address to log in the DVR remotely. Remote Click to go into the detailed Config DVR setting.

  • Page 44: General Operation

    REMOTE OPERATION Button Function Description Full Simplified Function recording of the selected log. Record / Click to start / stop the manual recording. Record Stop Click to take a snapshot of the current view. The Snapshot snapshot will be saved in the path you specified in “Record Setting”.

  • Page 45: Network Backup

    REMOTE OPERATION If “Manual” is checked, click “ ” or “ ” on the main control panel to start the manual recording immediately, and the recordings will be saved in the specified location. If “Motion” and / or “Alarm” are checked, the recording function will also be enabled at the remote side when any event is triggered at the DVR side, and the recordings will be saved in the specified location.
  • Page 46 REMOTE OPERATION Function Description HDD Number / Channel Specify the hard disk (HDD Number) and channel number (Channel) within which have the video data you need. Download by Time Specify the time range within which has the video data you want in the “Start Time”...

  • Page 47: Firmware Upgrade

    REMOTE OPERATION Firmware Upgrade This function is used to grade your DVR for function scalability. Note: Before using this function, make sure you have the correct upgrade files provided by your installer or distributor. Step1: Click “ ”, and select the IP address of your device in the address book. Step2: Click “...

  • Page 48: E-Map

    REMOTE OPERATION 6.1.4. E-Map Video Viewer is also a Central Management System (CMS) software, which allows network device control & management for up to 16 devices simultaneously. Note: Before using this function, make sure Video Viewer is connected to all the devices (up to 16) you want to monitor.
  • Page 49 REMOTE OPERATION...
  • Page 50 REMOTE OPERATION STEP3: When the E-Map group is created, you will see the tree on the top-left panel, showing all the devices you’ve added to this group. Icon Description The connected device is camera. When it’s selected, it will become red. The connected device is DVR.
  • Page 51 REMOTE OPERATION  For Single E-Map Group Right-click on the group name to show the shortcut menu list, and select “Edit E-MAP” or “Remove E-MAP” as needed.
  • Page 52 REMOTE OPERATION For Building E-Map Group  Right-click on the group name to show the shortcut menu list, and select “Edit Building E-MAP” or “Remove E-MAP” as needed. To edit or remove a certain level of the building E-Map group, right click on the level name, and select “Edit E-MAP”...

  • Page 53: Web Browser

    REMOTE OPERATION 6.2 Web Browser You can view the images or operate your DVR with a web browser, such as Internet Explorer, Mozilla Firefox or Google Chrome. Note: The supported PC operation systems are Windows 7, Vista & XP. Note: To use Mozilla Firefox or Google Chrome for remote access, please go to Apple’s official website (http://www.apple.com/quicktime/win.html) to download and install QuickTime first.
  • Page 54 REMOTE OPERATION Icon Description Click to go to the live view of the DVR. Click to enter the playback panel where you can search or select the event you want to play and download to your PC simultaneously. For details, please refer to “6.2.1 Event Download &...

  • Page 55: Event Download & Playback

    REMOTE OPERATION 6.2.1 Event Download & Playback Close all / Click to close the current playback video clip (in the red frame), or Close to close all playback video clips. Click to jump to the next / previous time interval in an hour, for example, 11:00 Previous / ~ 12:00 or 14:00 ~ 15:00, and start playing the earliest event video clip Next Hour...

  • Page 56: Appendix 1 Specifications

    APPENDIX 1 SPECIFICATIONS APPENDIX 1 SPECIFICATIONS  For 16CH Models Model 1 Model 2 Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 16 channels (composite video signal 1 Vp-p 75Ω BNC) Video Output (BNC) Main Monitor For stable display Video Output (VGA) Built-in (Resolution support up to 1600 x 1200)
  • Page 57 APPENDIX 1 SPECIFICATIONS Model 1 Model 2 Camera Title Supports up to 12 letters Video Adjustable Hue / Saturation / Contrast / Brightness Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY Daylight Saving Power Source (±10%) DC 19V Power Consumption (±10%) <...
  • Page 58 APPENDIX 1 SPECIFICATIONS  For 8CH Models Model 3 Model 4 Model 5 Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 8 channels (composite video signal 1 Vp-p 75Ω BNC) Video Output Built-in Built-in Audio Input / Output 4 audio inputs / 1 audio output (Mono) Maximum Recording Rate Frame...
  • Page 59 APPENDIX 1 SPECIFICATIONS Model 3 Model 4 Model 5 Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY Daylight Saving Power Source (±10%) DC 19V Power Consumption (±10%) < 64 W Operating Temperature ~ 40 (50 ~104 ) ℃ ℃ ℉ ℉ 430(W) x 65(H) x 432(W) ×...
  • Page 60 APPENDIX 1 SPECIFICATIONS  For 4CH Model Model 6 Model 7 Video System NTSC / PAL (auto detection) Video Compression Format H.264 Video Input 4 channels (composite video signal 1 Vp-p 75Ω BNC) Video Output (BNC) Main Monitor: For stable display Video Output (VGA) Built-in (Resolution support up to 1600 x 1200) Audio...
  • Page 61 APPENDIX 1 SPECIFICATIONS Model 6 Model 7 Alarm I/O 4 inputs, 1 output Key Lock (Password Protection) Local User Level Administrator & Operator Video Loss Detection Camera Title Supports up to 12 letters Video Adjustable Hue / Saturation / Contrast / Brightness Date Display Format YY/MM/DD, DD/MM/YY &...

  • Page 62: Appendix 2 Compatible Usb Flash Drive List

    APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST APPENDIX 2 COMPATIBLE USB FLASH DRIVE LIST Please upgrade the firmware of the DVR to the latest version to ensure the accuracy of the following table. If the USB flash drive is not supported by the DVR, the “USB ERROR” message will be shown on the screen.

  • Page 63: Appendix 3 Compatible Sata Hdd List

    APPENDIX 3 COMPATIBLE SATA HDD LIST APPENDIX 3 COMPATIBLE SATA HDD LIST Please upgrade the firmware of the DVR to the latest version to ensure the accuracy of the following table. MANUFACTURER MODEL CAPACITY ROTATION Seagate ST3320613AS 320GB 7200 rpm ST33500320AS 500GB 7200 rpm...

  • Page 64: Appendix 4 Main Menu Structure

    APPENDIX 4 MAIN MENU STRUCTURE APPENDIX 4 MAIN MENU STRUCTURE QUICK START GENERAL CHANNEL TITLE EVENT STATUS DATE DISPLAY MOUSE SENSITIVITY PRIORITY(For Model 7 Only) RECORD CONFIG TIME SETUP DATE TIME DATE SETUP DATE INFO DISPLAY DATE OF MODE FORMAT DAYLIGHT DAYLIGHT SAVING SYSTEM...
  • Page 65 APPENDIX 4 MAIN MENU STRUCTURE ADVANCED CONFIG NETWORK E-MAIL DDNS DISPLAY DE-INTERLACE (For Selected Models Only) FULL SCREEN DURATION QUAD SCREEN DURATION (For Selected Models Only) DISPLAY COVERT HDD DISPLAY MODE VGA OUTPUT ALPHA BLENDING RECORD MANUAL RECORD EVENT RECORD TIMER RECORD PRE-ALARM RECORD OVERWRITE...

  • Page 66: Appendix 5 Dvr Battery Replacement

    APPENDIX 5 DVR BATTERY REPLACEMENT APPENDIX 5 DVR BATTERY REPLACEMENT DVR time reset after power failure, for example, caused by a power outage, will cause the disorder of the recorded data, and users may have problems in searching the event clip they want.

  • Page 67: Appendix 6 Pin Configuration

    APPENDIX 6 PIN CONFIGURATION APPENDIX 6 PIN CONFIGURATION ‧ For Model 1 & 2 Siren: When the DVR is triggered by alarm or motion, the COM connects with NO and the siren with strobe starts wailing and flashing. Magnetic Contact: When the magnetic contact is opened, the alarm will be triggered and the recording is on.
  • Page 68 APPENDIX 6 PIN CONFIGURATION ‧ For Model 3 & 5 Siren: When the DVR is triggered by alarm or motion, the COM connects with NO and the siren with strobe starts wailing and flashing. Magnetic Contact: When the magnetic contact is opened, the alarm will be triggered and the recording is on.
  • Page 69 APPENDIX 6 PIN CONFIGURATION ‧ For Model 4 & 6 Siren: When the DVR is triggered by alarm or motion, the COM connects with NO and the siren with strobe starts wailing and flashing. Magnetic Contact: When the magnetic contact is opened, the alarm will be triggered and the recording is on.

  • Page 70: Appendix 7 Dvd Writer Installation

    APPENDIX 8 DVD- / CD-ROM COMPATIBLE LIST APPENDIX 8 DVD- / CD-ROM COMPATIBLE LIST ‧ DVD-ROM List Disc Type Manufacturer Disc MID-TID Code 20X DVD+R RITEK RITEK R05 (rev:och) 16X DVD+R SONY SONY..-D21 TAIYO YUDEN YUDEN000-T03 MITSUBISHI MCC..-004 TDK..-003 MAXELL MAXELL..003 MBIPG101-R05 CMC MAG.-M01...

  • Page 71: Appendix 8 Dvd- / Cd-Rom Compatible List

    APPENDIX 8 DVD- / CD-ROM COMPATIBLE LIST Disc Type Manufacturer Disc MID-TID Code 6X DVD-RW MITSUBISHI MCC 01RW6X01 JVC1Victord7 RITEK RITEK W06 4X DVD-RW MITSUBISHI MCC 01RW4X TDK601saku RITEK RITEKW04 2X DVD-RW MITSUBISHI MCC 01RW11N9 JVC_VictorW7 TDK502 sakuM3 CMCW02 RITEK RITEK W01 12X DVD-R9 MKM 04 RD30...
