7.01 Parts List Power Supply

Item Number Quantity
PARTS LIST
1 1 Cable Ground PG29
2 1 Case, Front
3 1 PCB-Front
4 1 Circuit Breaker
5 1 Cover Assembly 35C
6 1 Cooling Fan
7 1 Power Cord Strain Relief
8 1 Case, Back
9 1 Case, Top
10 1 PCB-Control
11 1 H/V PCB
12 1 Relay
13 1 Resistor
14 1 Control Transformer
15 1 Bracket, Capacitor
16 1 Electrolytic Capacitor Assembly
17 1 Bracket, Upper
18 1 Compressor Part
19 1 Current Sensor
20 1 PCB-Input Filter (shown)
20 1 PCB-Input Filter (CE)
21 1 Heat Sink Assembly
22 1 Case, Torch Cover
23 1 Connector
24 1 Pilot Relay Assembly
25 1 Main Trans and Reactor Assy
26 1 Compressor Assembly
27 1 Rubber Bushing
28 1 PCB-Torch Filter
29 1 Case, Bottom
Description Catalog Number
7-2
9-0382
9-0309
9-7117
9-7143
9-0310
9-7163
9-0296
9-0311
9-0312
9-7181
9-7147
9-0319
9-0300
9-7144
9-0302
9-0303
9-0313
9-0320
9-7153
9-7128
9-7133
9-0306
9-0314
9-0305
9-0304
9-0315
9-0316
9-0318
9-7121
9-0317
Manual 0-4745
