7.02 Replacement Hand Torch Parts With Ergonomic Handle

Item # Qty
1 1
2 2
3 1
4 1
1
5 1
6 1
7 1
8 1
9 1
10 1
11 3
12 3
13 3
14 3
15 1
NOTE: Item can be purchased locally.
PARTS LIST
Description
Assembly, Basic Head
70° Head
PIP (Parts - In - Place) Pins
#6-32 x 3/16" Phillips Pan Head Screw
#6 Internal Star Washer
Ergonomic Handle, Split, with Trigger (includes items #5 - 12)
Trigger, Lexan, Orange
Handle
Spring, 0.390 O.D. x 0.750
Torch Handle Socket Head Cap Screw Kit (5 pcs 6-32 x 1/2" )
Assembly, Torch Switch
Negative / Plasma Lead Insulation Sleeving
Pin Housing (Used with item #12)
Pin
Socket Housing (Used with item #14)
Socket
Lead Assembly, including items No. 6, 8, and 9
20 ft (7.6 m) Length
7-6
Catalog #
9-8442
9-5723
See Note
See Note
9-8076
9-8059
9-8060
9-8061
9-8062
9-8063
9-8056
9-8111
9-8101
9-8112
9-8102
4-2989
Manual 0-4745
