SECTION 2.0

INTRODUCTION

2.01 INTRODUCTION
Plasma is a gas which has been heated to an extremely
high temperature and ionized so that it becomes elec-
trically conductive. The plasma arc cutting process uses
this plasma to transfer an electrical arc to the work-
piece. The metal to be cut is melted by the heat of the
arc and then blown away.

2.02 GENERAL SPECIFICATION

M odel Desc ription
M ax im um output
Input V oltage & P has e
Frequency
Input power
Current Input fus e
No Load V oltage
Load V oltage
Output Current
P os t flow tim e
Duty cy c le @ 104°F /
40° C A m bient
Genuine Cutting
Capacity
M ax im um Cutting
Capacity
Dim ension (W * D * H)
Gross Weight
Refer to Local and National Codes or local au-
thority having jurisdiction for proper wiring re-
quirements.
Manual 0-4745
35C
35 A m ps
230V ,
S ingle P has e
50/60Hz
8.3 kV A
U.S . / Canada 40
A m ps
A ll others 16A S low
B low Fus e
330V
94V
10 - 35 A m ps
15 S econds
35% @ 35A @
94v dc
60% @ 27A @
91v dc
100% @ 20A @
88 vdc
3/8"
(10 m m )
5/8"
(15 m m )
10.5"x 15.5"x11"
(267 m m x 394 m m
x 279 m m )
57 lbs. (26 k g )
NOTE:

2.03 Features

• COMPACT and LIGHT - Designed for easy trans-
portation.
• ENERGY EFFICIENCY - Advanced technology
reduces power consumption.
• HIGH SPEED GENUINE CUTTING - The con-
stricted plasma arc provides high speed cutting
as well as a good quality genuine, narrow cut.
• LOW COST WITH COMPRESSED AIR - The 35C
operates on compressed air.
• ALL KINDS OF METALS - Useful for most met-
als such as stainless steel, aluminum, mild steel,
copper and their alloys.
• PILOT ARC IGNITION FROM TORCH - The Pi-
lot Arc ignites the cutting arc.
• POWERFUL CUTTING PERFORMANCE -
Genuine cutting capacity is 3/8" (10 mm) and
5/8" (15 mm) for maximum cut.
• ABLE TO CUT PAINTED MATERIALS - Pilot Arc
ignition allows the 35C to cut painted materials.
• EXTENDED PARTS LIFE - Consumable parts life
is longer.
2-1 Introduction
