SECTION 3.0

INSTALLATION

3.01 Site Selection

• Place in a clean and dry area.
• Provide adequate ventilation and fresh air sup-
ply.
• Ideal ambient temperature should not exceed
40°C / 104°F. Temperatures exceeding that may
diminish cutting capacity or quality.
• The cutting machine must be placed on an even,
flat surface so that it stands firmly.
This equipment must be electrically connected
by a qualified electrician.

3.02 Electrical Input Connections

• Input voltage is 230V ± 10%, 50/60 Hz single
phase.
Check your power source for correct voltage be-
fore plugging in or connecting the unit. The
primary power source, fuse, and any extension
cords used must conform to local electrical code
and the recommended circuit protection and wir-
ing requirements as specified in Section 2.
Manual 0-4745
WARNING
CAUTION

3.03 Torch

• Make sure that the torch cable and torch switch
terminals are connected to front panel.
• Make sure the Work Cable is connected properly
to front panel.
• Before activating, turn torch away from yourself
and others.
Do not cut in humid or wet surroundings.
• Before you maintain or replace torch parts, wait
for the post flow air cycle to stop (approximately
15 seconds), then turn the machine off.
• Always use original manufacturers parts. The use
of aftermarket parts could result in lower parts
life and in unsatisfactory cutting results. Any war-
ranty claims would be waived.
• Recycle worn parts according to local require-
ments.
Repairs must be done by skilled and qualified
personnel only.
3-1
DANGER
NOTE
Installation
