Section 8: Barcodes
Example:
<x
1B5B66
0600
B4
00
00
5000
00
1B5B70
0400
30 33 39 32
0D0A0A0A0A0A0A
>
Barcode data and other print data (for example, text data) are controlled
independently. It is necessary to provide sufficient horizontal space for the
barcode when mixing barcodes with other data, otherwise, the text and
barcode data will overlap, as shown in the following example:
Example:
<x1B5B66 0600 B4 00 00 3804 00>
Barcode Print Sample: <x1B5B70 0300> 395 Text Printing
<x0A0A0A0A0A>
Barcode Print Sample:
- barcode setup command prefix
- setup data length (low byte
first) - x0006, 6
- barcode type = Code 39
- module width = default
- space width adjustment = default
- height (low byte first) - x0050
= 0.037 inches
- control byte
- barcode data transfer command
prefix
- data transfer length (low byte
first) - x0004, 4
- data string "0392"
- 1 carriage return and 6 line
feeds
