Print Speeds; Printhead Description; 248X - Lexmark FORMS 249X Technical Reference

Print Speeds

Your printer supports the following burst print speeds in characters per
second (cps).
Mode
Fast Draft
• 10 cpi
• 12 cpi
Draft
• 10 cpi
• 12 cpi
Near Letter Quality -
Gothic, Courier
• 10 cpi
• 12 cpi
Letter Quality -
Prestige, Presentor,
Orator, and Script
• 10 cpi

Printhead Description

Your printer uses dot-matrix impact technology to generate characters. The 248x
has a 9-wire printhead. The 249x has a 24-wire printhead.

248x

The 248x printhead has nine wires arranged in a single vertical column. The
diameter of each wire is 0.30 mm (0.012 in.). The center-to-center distance
between wires is 0.353 mm (1/72 in.). The printhead has an impact force
sufficient to generate readable copies on multipart forms and envelopes up to
and including 6-ply forms (original plus 5 copies).
249x
The 249x printhead has twenty-four wires arranged in two parallel vertical
columns of twelve wires each. The diameter of each wire is 0.22 mm (0.009 in.).
The wires in each of the rows are vertically separated to produce a 0.141 mm (1/
180 in.) space between the centers of adjacent dots. The printhead has an impact
force sufficient to generate readable copies on multipart forms and envelopes
up to and including 4-ply forms (original plus 3 copies).
2480/2481 2490/2491
• 438 cps • 409 cps
• 510 cps • 465 cps
• 309 cps • 274 cps
• 304 cps • 328 cps
• 77 cps • 91 cps
• 76 cps • 109 cps
N/A 91 cps
Section 1: Introduction
9
