Lexmark FORMS 249X Technical Reference page 164

data character set:
Character
Examples:
Valid Interleaved 2of5 command:
<x
1B5B66
0600
B6
00
00
1003
01
1B5B70
0400
>2359 ...
Since the b0 bit of the c parameter has a value of 01 (check digit by printer), note
the 0 character added to the barcode above.
164
Section 8: Barcodes
Hex
'0' x30
'1' x31
'2' x32
'3' x33
'4' x34
'5' x35
'6' x36
'7' x37
'8' x38
'9' x39
- barcode setup command prefix
- setup data length (low byte first) -
x0006, 6
- barcode type = Interleaved 2of5
- module width = default
- space width adjustment = default
- height (low byte first) - x0310 = 784 =
0.363 inches
- control byte: check digit from host,
print human readable character
- barcode data transfer command prefix
- data transfer length (low byte first) -
x0004, 4
