AT840 Series User Manual
on the area code and number.
(1 xxx xxxxxxx)
The following also allows 7-digit US-style dialing, and automatically inserts a 1 + 212 (local area
code) in the transmitted number.
(1 xxx xxxxxxx | <:1212> xxxxxxx)
For an office environment, the following plan requires a user to dial 8 as a prefix for local calls and
9 as a prefix for long distance. In either case, an "outside line" tone is played after the initial 8
or 9, and neither prefix is transmitted when initiating the call.
(<9, :> 1 xxx xxxxxxx | <8,:1212> xxxxxxx )
The following allows only placing international calls (011 call), with an arbitrary number of digits
past a required 5 digit minimum, and also allows calling an international call operator (00). In
addition, it lengthens the default short interdigit timeout to 4 seconds.
S: 4, (00 | 011 xxxxx x.)
The following allows only US-style 1 + area-code + local-number, but disallows area codes and
local numbers starting with 0 or 1. It also allows 411, 911, and operator calls (0).
(0 | [49]11 | 1 [2-9] xx [2-9] xxxxxx)
The following allows US-style long distance, but blocks 9xx area codes. (1 [2-8] xx [2-9]
xxxxxx)
The following allows arbitrary long distance dialing, but explicitly blocks the 947 area code. (1
947 xxxxxxx! | 1 xxx xxxxxxx)
The following implements a Hot Line phone, which automatically calls 1 212 5551234. (S0
<:12125551234>)
The following provides a Warm Line to a local office operator (1000) after 5 seconds, unless a 4
digit extension is dialed by the user.
(P5 <:1000> | xxxx)

4. Web settings

Enter AT840 IP addresses in the web browser to go to the log on page, then you will access
AT840's user webpage.
Click "admin" which is on the right corner to enter administrator webpage.
NAM TRUONG GIANG
www.lapdattongdaidienthoai.com
19
