AT840 Series User Manual
VPN Enable: whether enable VPN

VPN Type: only support L2TP VPN

Server address: VPN server address

Username: VPN account's username

Password: VPN account's password

After apply, the phone will reboot. The VPN ip will show on the System Status page.
VLAN

Use Vlan Tagging: vlan tag or untag

Voice VLAN Identifier(1..4094) : Assign VLAN id for voice stream between 1 to 4094

Voice VLAN Priority : the degree is 0-7, 7 is the highest priority.

Data VLAN Identifier(1..4094) : Assign VLAN id for data stream between 1 to 4094

Data VLAN Priority : the degree is 0-7, 7 is the highest priority.

Port Link

Choose the type of the WAN/PC network port link
WAN Port Link: Auto negotiate, full duplex 10Mbps, full duplex 100Mbps, half duplex 10Mbps,

half duplex 100Mbps.
PC Port Link: Auto negotiate, full duplex 10Mbps, full duplex 100Mbps, half duplex 10Mbps,

half duplex 100Mbps.
Qos

Quality of service
SIP Qos: Quality of service for SIP (Diffserv)

