MTH400 User Manual
The following table sums up which parameters can be set and the related range settings.
MENU PARAMETER
CH
GR
Freq
TUNING
AF Gain
Phase
AUDIO
HP
Noise R.
RF Power
RF/BATTERY
Battery
Led Light
Led Mode
LED
PTT Mode
MIC
10
Rev.05
MEANING RANGE SETTINGS
Channel 0 ÷ 59
Group 0 ÷ 39 + SYNC GROUP
Frequency It depends on the MTH400 Model:
Gain of the -20dB ÷ 40dB step of 1 dB
audio signal
Audio signal 0° or 180°
phase
High Pass filter Flat/60/80/120/170/250/400 Hz
Noise reduction ENR: Wisycom Extended-NR, noise optimized
ENC: Wisycom Extended-NC, voice optimized
RF Power 10mW or 50mW or 100mW (depending on the
power profile)
Battery type Alkaline or NiMH
Power switch 0 ÷ 16
green
brightness
It defines when None: never
the power ModPeak: when audio get close to saturation
switch led (see PTT: when the PTT button is pushed
Fig. 3) has to
become RED
It defines how Disable: when the PTT button is pushed, nothing
and what happen. (the transmitter sends AF+Tone
information the squelch)
transmitter has Normal: when the PTT button is pushed, the
to send transmitter send a different RF signal. According
to the receiver configuration the audio can be
enabled/disable on LINE (and/or COM).
Muting: the transmitter doesn't send the audio.
The voice is cut, it doesn't enter to the
microphone
No Data: the transmitter sends neither tone
squelch nor battery data.
1 470-640
2 566-798
3 510-698
