INTEGRA
4. The change of access code has been blocked, because the code has been „hit" by
another user trying to change his own code. If the option to remind of the need to change
the code is enabled, each use of such a „hit" code will be signaled by three double beeps.
If this is the case, the access code change will only be possible by means of the LCD
keypad - with a necessary change confirmation (see description of the C
function) by the object administrator. This feature prevents the access code and its
authority from being „intercepted" by the user who accidentally has „hit" the password.
Note: In case of a large number of users, it is recommended that longer, at least 5-digit
access codes be used in order to reduce the probability of another user code being
„hit". The CLC/TS 50131-3 standard requires that 6-digit access codes be used.
Information conveyed by the keypad by means of the LED indicators has been described in
section P
ARTITION KEYPADS
simultaneously that it is waiting for the card to be read in (during the procedure of adding
a card to the user).
The partition keypad with proximity card reader can generate the following audible signals:
• One short beep – confirmation of access code entry (the A
( ) option must be enabled by the installer) or card read-in (the S
HARDWARE
( ) option must be enabled by the installer).
HARDWARE
• One long beep – refusal to arm.
• Two long beeps – access code / card unknown to the control panel.
• Two short beeps – acceptance of the first out of two access codes required for arming or
disarming.
• Three long beeps – access code / card cannot control the given partition.
• Three short beeps – confirmation of arming / disarming.
• Three pairs of short beeps – the user code needs to be changed (the N
NECESSITY TO CHANGE ACCESS CODE
• Four short beeps and one long beep – confirmation of control function execution,
change of access code, confirmation of guard rounds.
• Five short beeps – dependent door open – lock control has not been executed. In order
to operate the lock, close the dependent door and enter the code / read in the card again.
The audible signaling may be replaced by blinking of the keys backlight PROG. The beeps
will translate, respectively, into keypad backlight extinguishments – if the backlight is ON, or
into keypad backlight going on - if it is normally OFF.
The keypad can also signal other situations, as selected by the installer (see section
P
ARTITION KEYPADS

6.5.3 Operation in entry keypad mode (INT-ENT)

The main task of the entry keypad is to unblock the delay for zones with reaction time
3. I
NTERIOR DELAYED
programmable for the keypad. If several entry keypads are assigned to one partition,
a different time of delay activation can be programmed for each of them. After the
programmed time period expires, the interior delayed zones will again act as instant ones.
The keypad will execute its functions after:
– entering the access code and confirming it with the
– entering the access code and confirming it with the
– presenting the card.
Apart from the delay activation, the entry keypad may also execute the following functions:
– 24. MONO S
WITCH
. Additionally, the keypad can signal by all the LEDs blinking
).
. The time period during which these zones will act as delayed ones is
output control
SATEL
option is enabled in the control panel).
HANGE OWN CODE
CCESS CODE SIGNALING
key,
key,
23
.
IGN CARD
OTIFY OF
