6.2.4 Audible signals

When using the keypad the following signals, characteristic of some situations, can be heard
PROG.
• One long beep – refusal of arming - the zone, which shouldn't be violated at the time of
arming, is violated (P
keypad. The refusal includes all zones selected for arming. Also, warning of the system
failure - prior to arming.
• Two long beeps – the code not recognized by the control panel; function not accessible;
wrong data; acknowledgement of canceling the selected function (after pressing [ * ] on the
keypad); pressed key is not active; card code not recognized.
• Three long beeps – the code is recognized, but the function called is not accessible (for
example, temporary partition blocking is activated or the user has no access to partitions
operated from the keypad).
• Two short beeps – selection accepted – entering more detailed menu level.
• Three short beeps – acknowledgement of arming or disarming.
• Four short and one long beeps – acceptance of execution of the selected function.
• Three pairs of short beeps – it is necessary to change the code (for example, another
user, when changing his code, indicated the combination of digits identical with that in the
given user code; the code validity is expiring).
Additionally, the following situations may be signaled:
•
Alarm in partition –
service).
•
Fire alarm
– series of long beeps every second for the total alarm duration.
•
Countdown of entry delay
Note: The signaling of entry delay countdown by 2 short beeps refers to the LCD keypads
type INT-KLCD-GR/BL and INT-KLCDR-GR/BL with firmware in version 1.05, and to
the keypads type INT-KLCDL-GR/BL, INT-KLCDS-GR/BL and INT-KLCDK-GR with
firmware in version 6.05. In keypads with earlier firmware versions, the entry delay
countdown is signaled by short beeps every 3 seconds.
•
Countdown of exit delay
short beeps (for 10 seconds) and a single long beep. The way of "exit delay" signaling
informs that the countdown is ending prior to arming.
•
Auto arming delay countdown
diminishing length).
•
Chime in LCD keypad
detectors when the zone is disarmed.
6.3 U LCD
SING
Operation of the system from LCD keypad starts with entering the user CODE and pressing
the key marked [#], [ok] or [ * ]. The control panel response (accessible functions) after
pressing the [#] or [ok] key is different than that after pressing [ * ].
[CODE][#] or [CODE][ok] you get access to functions of arming/disarming type,
[CODE][ * ] you get access to all functions in the user menu to which the user is authorized.
Example: When you enter your code and press [#], the control panel will make available the
functions of partition arming (provided that no partition, operated from the LCD keypad, is
already armed) or disarming (if any of partitions is armed). In the event of alarm occurrence
in the system, the control panel may cancel this alarm and provide access to the function of
partition disarming (if the user is authorized to do that). When the function of telephone
messaging is activated – the Clear voice messaging function may appear in menu. When the
option), there was a trouble with the battery, expander, or
RIORITY
continuous beep for the total alarm duration (time programmed by
– 2 short beeps every second.
– long beeps every 3 seconds, completed with a series of
– five short beeps – this is a response to activation of some
KEYPAD
User Manual
(timer-controlled partitions) – a series of 7 sounds (of
INTEGRA
