14
For each of the functions the installer determines the number of partition, zone or output it
refers to. The user, who wants to perform the given function must have an appropriate
authority level and access to the selected partitions.
The control panel may fail to arm the system, if the selected partitions contain a violated zone
which is monitored during arming.
All user functions, which are accessible from LCD keypad, are described in section
"Description Of User Functions".

6.3.1 Selecting functions from menu

When the control panel has recognized the code, the first user function (from all functions
accessible at the moment) will appear in the upper line of the display. You can move through
the list of functions made available by the control panel by pressing
required item from the list (single-selection list) by pressing [#] or
requires making further selection (submenu, options), the next list appears on the display,
which allows you to select required item in a similar way.
Some functions may need selection of a few items from the list (multi-selection list). To do
that, scroll the list by pressing
selected. The item is marked by pressing any numeric key, then the
upper display corner next to the text. Press the numeric key again to cancel you selection.
By scrolling the list upwards or downwards (the list contents is displayed cyclically), you can
see all the items and check the selections. Pressing the [#] or
(execution of function may be confirmed with a beep), and the control panel returns to
previously displayed menu or displays a corresponding message and returns to the basic
status (waiting for code). Then, current date and time is displayed. Date and time display
format is defined by the installer PROG.
There is a control panel setting option which activates the procedure of double confirmation
of some user functions. After pressing the [#] or
a prompt appears on the screen asking to confirm the function, together with information:
1=Yes. Press the key with digit 1 to confirm this function. This procedure is a safeguard
against accidental double pressing [#] (or
be executed. The description of user functions in this Manual relates to situation when this
option is switched off.
If you want to give up the selection of function after opening the User Menu, press the [ * ] key.
If no keypad button is pressed (within 2 minutes) after menu opening, the control panel will
automatically close this menu and return to its basic status.

6.3.2 Entering data

Some functions require entering a new code or user name. The way of entering the new data
that relate to system users is described below. When changing the code, the control panel
does not show the old code, unless the user has not yet changed the code assigned to him
by the person introducing him into the system. However, the old name always is shown on
the display when the old name is being changed. The entered user name appears in
selection lists, printouts and when viewing the events log in the computer.
• new code, time limit: numeric data are entered by means of the numeric keys. The arrow
keys are used for modification of numbers to be entered. Below the text field, where the
entered digits appear, a cursor (dash) can be seen. The
moving the cursor to show the successive digits. Press the key with a digit to enter the
given digit at the left side of cursor, and press the
side of cursor. The
This type of cursor allows changing the digit above the dash to the digit entered from the
keyboard. Press the
User Manual
and key and "mark" all items in the list, which should be
arrow changes the cursor type – a blinking dark rectangle appears.
key again to return to the previous cursor type.
key (normal mode of selecting a function),
) and execution of function, which should not yet
arrow to delete the digit at the left
and , and select the
. If the selected function
symbol appears in the
key accepts the selection
and arrows are used for
INTEGRA
