CONTROL FREAK
Request for 64 byte single data dump (also Button/F key etc.)
F0h, 00h, 20h, 13h, 08h, 10h , 40h, prog_num , slider_num , F7h
where prog_num is a (decimal) number between 0 and 127
where slider_num is as follows (decimal) :
0 – 7
16 – 23
32 – 39
48 – 55
64 – 71
96 – 103
112 – 119
The Control Freak responds with the specified 64 bytes of data
For example: to request a dump of program 6 button-on 3 you would send the following:
F0h, 00h, 20h, 13h, 08h, 10h , 40h, 06h , 12h , F7h
Note that 12h is the hexadecimal equivalent of decimal 18 for selecting button-on 3
Request for 64k Block data dump
F0h, 00h, 20h, 13h, 08h, 10h , 50h, block_num , F7h
where block_num is as follows (decimal)
0
1
2
3
The Control Freak responds with the specified 64k bytes of data
For example: to request a dump of all button-off data you would send the following:
F0h, 00h, 20h, 13h, 08h, 10h , 50h, 02h , F7h
Request for 64k Library data dump
F0h, 00h, 20h, 13h, 08h, 10h , 60h, library_num , F7h
as above except library_num can be 0 or 1 only to select library 1 or 2
Request for 256k all 128 programs data dump
F0h, 00h, 20h, 13h, 08h, 10h , 50h, 06h, F7h
The Control Freak responds with 256k bytes of data in a packed format where approx 293k bytes
of data are actually transmitted. Note to actually respond to this dump the memory of the Freak
must be completely wiped first.To do this turn the Freak on with all four F.keys pressed.
Request for 1600 byte Complete Program dump
prog data + 8 sliders + 8 button-on – 8 button-off ( =25x64)
F0h, 00h, 20h, 13h, 08h, 10h , 70h, prog_num, F7h
where prog_num is a (decimal) number between 0 and 127
The Control Freak responds with the specified 1600 bytes of data.
For example: to request a dump of program #33 you would send the following:
F0h, 00h, 20h, 13h, 08h, 10h , 70h, 21h , F7h
Note that 21h is the hexadecimal equivalent of decimal 33 for selecting the program
Sliders 1 to 8
Button-on 1 to 8
Button-off 1 to 8
Function key-on 1 to 8
Function key-off 1 to 8
Program (all 8 values return the same program data)
Global (all 8 values return the same global data)
All Slider data (data from all 1024 sliders)
All Button-on data
All Button-off data
All Program data / Funtion keys-on/off / Global
SYSTEM EXCLUSIVE
