DATA VARIABLES

Data variables
Data`Val`00h`0``
Data`from`Slider
Use`Data`frm`S01
Use`Data`frm`S16
Use`R/T`Value`#1
Use`R/T`Value`#2
Data`Val`7Fh`127
Data`Val`01h```1
End`Sysex``[F7]`
Sx`14b`signed`LH
Sx`14b`signed`HL
Sx`Ascii`M/I/LSB
Sx`Data`0Hh/0Lh`
Sx`Data`0Lh/0Hh`
Sx`4x4`nibl`HhLl
Sx`4x4`nibl`lLhH
Progrm`Sysex`Hdr
Global`Sysex`Hdr
````Checksum
22
Most commands require some data to be entered at the subsequent screens.
The following data variables can be used at any of these screens.
The table lists the data types in the order you see them as you turn the Data
Wheel to the left (anti-clockwise).
Fixed numeric value of zero
Data is taken from local slider
Data is taken from another slider – in this case slider #1
Other sliders S02 to S15 (Freak
Data is taken from slider #16
Byte definable by user in real-time
Byte definable by user in real-time
Fixed numeric value of 127 – note the hexadecimal value given too
Fixed numeric values 126 to 2
Fixed numeric value of 1
Note that if you are entering a controller number at the screen following a
controller command, the Freak gives you the standard names for the
controllers as well as the numeric value.
There are some additional data variables which are only available when you are
entering data following a SysEx command.These additional variables appear in-
between some of the variables listed above and are as follows, again in the
order you see them as you turn the Data Wheel to the left (anti-clockwise):
Obligatory end byte for SysEx message
See SysEx explained page 40
See SysEx explained page 40
Format only used by Korg Wavestation (as far as we know)
See SysEx explained page 40
See SysEx explained page 40
See SysEx explained page 40
See SysEx explained page 40
String definable at program level
String definable at global level
Automatically calculates the checksum (mainly Roland).
CONTROL FREAK
only goes up to S08)
