EDITING EXAMPLES
Example of making a button send a chord on the Global MIDI channel – taking the velocity from the local
silder (the one directly beneath the button)
For this example we will send middle C and the major third and fifth above it.These correspond
to MIDI note numbers 60, 64 and 67
Press the [–– >] key from home position to start edit and display the edit menu options.
Turn the Data Wheel to the right (clockwise) until the display shows
Press the [–– >] key and use the Data Wheel to select the Button to Edit
Press the [–– >] key – leave Minimum Levl at 0
Press the [–– >] key – leave Maximum Levl at 127
Press the [–– >] key – the display will show:
Turn the Data Wheel one click to the right – the display will show:
Press the [–– >] key – the display will show:
Turn the Data Wheel three clicks to the right and the display will show:
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the [–– >] key – the display will show:
Turn the Data Wheel one click to the left to display:
Press the [–– >] key – the display will show:
Turn the Data Wheel three clicks to the right to display:
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) to display:
Press the [–– >] key – the display will show:
Turn the Data Wheel one click to to the left to show:
Press the [–– >] key – the display will show:
Turn the Data Wheel three clicks to the right to display:
26
CONTROL FREAK
EDIT`PB``ON`DATA
``Header``Data
`Button`ON`only
`Button`On`+`Off
````COMMAND
``End`of`DATA
```Note-On
```Note`Number
Data`Val`00h```0
Data`Val`3Ch``60
````Velocity````
Data`Val`00h```0
Data`from`Slider
````COMMAND
`End`of`DATA
```Note-On
```Note`Number
Data`Val`00h```0
Data`Val`40h``64
````Velocity````
Data`Val`00h```0
Data`from`Slider
````COMMAND
``End`of`DATA
```Note-On
