EDITING EXAMPLES
Press the [–– >] key – the display will show
Press the [STORE] key to save your data
Press the [EXIT] key to go back to PLAY MODE
As you can see from the above, you have to send the message twice. Setting the channel then
sending the message, then setting a new channel and sending the message again.
You can send any combination of messages up to the maximum the Freak allows – that is until you
can't press the
NB: the 'Set MIDI Channel command' must come before a MIDI message if you want it to apply to
that message.You can reset MIDI Channels as many times as you like in any slider / button.
Example of sending increasing MIDI volume message on one MIDI channel and sending decreasing MIDI
volume message on another MIDI channel – all from one slider
How to make a slider send MIDI volume on two MIDI channels at the same time with one
increasing whilst the other decreases. In other words, a pan from one channel to another.
In the example below, we're using MIDI Channels 1 & 2 – it is very similar to the previous
example, but with the addition of an 'Invert Data' command.
Press the [–– >] key from home position to start edit and display the edit menu options.
Turn the Data Wheel to the right (clockwise) until the the display shows:
Press the [–– >] key and use the Data Wheel to select the Slider to Edit
Press the [–– >] key – leave Minimum Levl at 0
Press the [–– >] key – leave Maximum Levl at 127
Press the [–– >] key – the display will show:
Turn the Data Wheel to the left (anti-clockwise) until the display shows:
Press the [–– >] key – the display will again show:
Turn the Data Wheel one click to the right - the display will show:
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the [–– >] key – the display will show:
Turn the Data Wheel one click to the left - the display will show:
30
[–– >] key any more (45 bytes).
CONTROL FREAK
````COMMAND
``End`of`DATA
UPDATING`MEMORY
EDIT`SLIDER`DATA
````COMMAND
``End`of`DATA
Set`MIDI Chan``1
````COMMAND
``End`of`DATA
```Controller
Controller`Numbr
0``Bank`Select
7``Main`Volume
Controller`Value
Data`Val`00h```0
Data`from`Slider
