EDITING EXAMPLES
Example of programming a button to send a System Exclusive Message (SysEx)
For this example we are going to send a General MIDI System On message which comprises six
bytes as follows: (in hexadecimal) F0h, 7Eh, 7Fh, 09h, 01h, F7h.
Press the [–– >] key from home position to start edit and display the edit menu options.
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the [–– >] key and use the Data Wheel to select the Button to Edit
Press the [–– >] key – leave Minimum Levl at 0
Press the [–– >] key – leave Maximum Levl at 127
Press the [–– >] key – leave Button ON only
Press the [–– >] key – the display will show:
Turn the Data Wheel two clicks to the right and the display will show:
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) until the display shows:
You can speed up the process by holding the shift key down whilst you turn the Data Wheel.
Press the [–– >] key – the display will show:
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the
Turn the Data Wheel to the right (clockwise) until the display shows:
Press the
Turn the Data Wheel to the right (clockwise) until the display shows:
Turn the Data Wheel two clicks to the left and the display will show:
Press the [–– >] key – the display will show:
Press the [STORE] key to save your data
Press the [EXIT] key to go back to PLAY MODE
NB: the byte number indication on the top line begins with the byte after the F0h.
32
key – for Byte #3
[–– >]
key – for Byte #4
[–– >]
CONTROL FREAK
EDIT`PB``ON`DATA
````COMMAND
``End`of`DATA
Begin`Sysex`[F0]
Byte`#``1``Sysex
Data`Val`00h```0
Data`Val`7Eh`126
Byte`#``2``Sysex
Data`Val`00h```0
Data`Val`7Fh`127
Data`Val`09h```9
Data`Val 01h```1
`End Sysex``[F7]
````COMMAND
``End`of`DATA
UPDATING`MEMORY
